Fdb Audio Double 6 Inch Line Array Speaker Professional Speaker Outdoor PA Speaker Line Array System
- Rated Power
- 160W RMS, 1280W Peak
- Impedance
- 8 Ohms Nominal
- Sensitivity
- 96dB 1 Watt/1 Meter
- Certification
- CE, RoHS
- Frequency Response(-3dB)
- 90Hz-18kHz
- Woofer
- 2X6"(150mm)/1.5" Voice Coil Woofer
Specifications
| Product name | Fdb Audio Double 6 Inch Line Array Speaker Professional Speaker Outdoor PA Speaker Line Array System |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Certification | CE, RoHS |
| Frequency Response(-3dB) | 90Hz-18kHz |
| Model NO. | MLA206&MLA115B |
| Woofer | 2X6"(150mm)/1.5" Voice Coil Woofer |
| Driver | 1X1"(25mm)/1.7" Voice Coil Tweeter |
| Rated Power | 160W RMS, 1280W Peak |
| Sensitivity | 96dB 1 Watt/1 Meter |
| Impedance | 8 Ohms Nominal |
| Maximum Spl | 118b Continuous, 124dB Peak |
| Dispersion(-6dB) | Horizontal:110 |
| Crossover Frequencies | 700Hz, 1.9kHz Passive |
| Transport Package | Carton Box/Flight Case |
| Specification | 480x332x221mm(MLA206); 480x680x458mm(MLA115S) |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 5000PCS/Month |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Web | fdbaudiochina.en.made-in-china.com |
| Horizontal | 110° |
| Price | US$1.00-3,000.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Rated Power | |
|---|---|
| Impedance | 8 Ohms Nominal |
Additional data
| FREQUENCY RESPONSE(-3dB) | 90Hz-18kHz |
|---|---|
| DRIVERS | 2×6"(150mm)/1.5"voice coil LF |
| 1×1"(25mm)/1.7"voice coil HF | |
| RATED POWER | 160W RMS,640W peak |
| SENSITIVITY | 96dB 1watt/1 meter |
| MAXIMUM SPL | 118 dB continuous,124 dB peak |
| IMPEDANCE | 8 ohms nominal |
| DISPERSION(-6dB) | Horizontal: 110° |
| CROSSOVER FREQUENCIES | 700Hz, 1.9kHz passive |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKING SIZE | 412mm×270mm×565mm |
| NET WEIGHT | 9.5 kg/pc |
| GROSS WEIGHT | 10.6 kg/pc |
Product description
The supplier lists this product. The listed model is MLA206&MLA115B. The specifications below reflect the information publicly displayed on the listing. Frequency Response(-3dB): 90Hz-18kHz. Model NO.: MLA206&MLA115B. Driver: 1X1"(25mm)/1.7" Voice Coil Tweeter. Rated Power: 160W RMS, 1280W Peak. Sensitivity: 96dB 1 Watt/1 Meter. Impedance: 8 Ohms Nominal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Fdb Audio Double 6 Inch Line Array Speaker Professional Speaker?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Fdb Audio Double 6 Inch Line Array Speaker Professional Speaker cost?
The published price is US$1.00 – 3,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
