Folded Horn Line Array New Audio Stage Sound System
- Power
- 2000watt RMS Each Cabinet
- Frequency Response
- 52Hz-20KHz± 3dB
- Sensitivity
- LF 104dB(1W@1M) MF 107dB(1W@1M) HF 111dB(1W@1M)
- Type
- Passive Three Way Line Array Speaker System
- Application
- Commercial
- Certification
- CE, RoHS
Specifications
| Product name | Folded Horn Line Array New Audio Stage Sound System |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Application | Commercial |
| Certification | CE, RoHS |
| Model NO. | CVR. W-8 |
| Type | Passive Three Way Line Array Speaker System |
| Size | 12"X2 Lf, 6.5"X4 Mf, 3"X2hf |
| Power | 2000watt RMS Each Cabinet |
| Cabinet | Birch Plywood Cabinet |
| Painting | Waterproof Textured Painting |
| Brand | Cvr PRO Audio |
| Transport Package | Carton |
| Specification | HIGH QUALITY |
| Origin | Guagnzhou, China |
| HS Code | 851822 |
| Production Capacity | 5000PCS/Month |
| Model | W-8 |
| Frequency Response | 52Hz-20KHz± 3dB |
| Power handling | LF 2× 600W(RMS)2× 1200W(PEAK) |
| Sensitivity | LF 104dB(1W@1M) MF 107dB(1W@1M) HF 111dB(1W@1M) |
| Max@S. P. L | LF 135dB(PEAK/1M) MF 135dB(PEAK/1M) HF 134dB(PEAK/1M) |
| LF section | 2× 12" (310mm)neodymium woofer 75mm(3in) coil |
| Nominal impedance | 8 ohm |
| MF section | 4× 6.5" (170mm)neodymium MF 50mm(2in)coil |
| HF section | 2× 3"neodymium compression driver with 75mm titanium diaphragm |
| Output section | 3-channel |
| Dispersion pattern | 110° H× 7.5° V |
| Finish | Water-proof, wear-resistant textured black paint |
| Speaker cables | LF 1(+)1(-) 2(+)2(-) MF 3(+)3(-) HF 4(+)4(-) |
| Rigging system | Please refer to the W-8 user manual before any operation |
| Input connectors | 2× Neutrik NL8 |
| Recommend crossover | LF 60Hz-600Hz MF 600Hz-1.8kHz HF 1.8kHz-20KHz |
| Dimensions | 1100× 405× 595mm(W× H× D) |
| Package dimensions | 1170× 475× 665mm/0.37cbm |
| Enclosure | Birch Plywood |
| Net weight | 60kg |
| Gross weight | 64kg |
| Price | US$200.00-2,000.00 1 Piece(MOQ) |
| Supplier | CVR PRO AUDIO CO.,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Size | |
|---|---|
| Power | 2000watt RMS Each Cabinet |
| Power handling | LF 2× 600W(RMS)2× 1200W(PEAK) |
| Nominal impedance | 8 ohm |
| Input connectors | 2× Neutrik NL8 |
Product description
The supplier lists this product as Passive Three Way Line Array Speaker System. Its stated application is Commercial. The listed model is CVR. W-8. The specifications below reflect the information publicly displayed on the listing. Model NO.: CVR. W-8. Power: 2000watt RMS Each Cabinet. Model: W-8. Frequency Response: 52Hz-20KHz± 3dB. Power handling: LF 2× 600W(RMS)2× 1200W(PEAK). Sensitivity: LF 104dB(1W@1M) MF 107dB(1W@1M) HF 111dB(1W@1M). Nominal impedance: 8 ohm. Input connectors: 2× Neutrik NL8.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Folded Horn Line Array New Audio Stage Sound System?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Folded Horn Line Array New Audio Stage Sound System cost?
The published price is US$200.00 – 2,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
CVR. W-8 · US$200.00 – 2,000.00 · MOQ 1 Piece
