Full Range Custom Raw Frame Speakers 15W 8ohm 78mm Low Frequency for Music Box
Speaker Drivers, Woofers & Tweeters

Full Range Custom Raw Frame Speakers 15W 8ohm 78mm Low Frequency for Music Box

Model: YD78-15 Customization available Speaker Parts & Accessories
US$3.00 – 5.00
MOQ 2,000 Pieces
Material
Metal
Type
Speaker
Application
Car Speaker etc
Color
Black
Speaker Design
Tweeter
Shape
Runway Shape
Send Inquiry Full specifications

Specifications

Product nameFull Range Custom Raw Frame Speakers 15W 8ohm 78mm Low Frequency for Music Box
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
TypeSpeaker
Speaker DesignTweeter
Model NO.YD78-15
ShapeRunway Shape
MaterialMetal
Sound FrequencyHigh Pitch
Voltage1V
Energy Exchanging MechanismElectrical
ColorBlack
FeatureFull Frequency
FunctionMicro Speaker
ApplicationCar Speaker etc
Transport Package1000 Pieces Per Carton
Specificationmetal
OriginChina
HS Code8518290000
Production Capacity300000 Pieces Per Month
PriceUS$3.00-5.00 2,000 Pieces(MOQ)
SupplierChangzhou Wujin Yueda Electroacoustic Equipment Co., Ltd.
Data retrieved2026-10-23

Available options

MaterialMetal
Voltage1V
ColorBlack

Additional data

Sound pressure80±3(A)AT 1m/1w
VOICE COLL IMP8Ω
RESONANT FREQ100±20% HZ
Temperature-25°C ~ 55°C
RATED POWER15W
MAX POWER20W
Weight285g
NO.ITEMSPECIFICATIONTESTING CONDITION
1NOMINAL SIZEφ78MM
2VOICE COLL IMP8Ohm ±15%
3RESONANT FREQfo 100±20% HZ
4OUTPUT S.P.L80±3dBAT 1m/1w MEASUREMENT
5FREQ RESPONSEfo~ 4K Hz -10dB-10dB
6RATED POWER15W
7MAX POWER20 W
8DISTORTION≤ 7 %Max
9OPEARTIONMUST BE NORMALPROGRAM SOURCE 0.1 W
10NOISEMUST BE NORMALSIN WAVE 3.1 V
11HEAT TESTAFTER TEST MEET ITEM 8,955± 2ºC 16 HOURS
12HUMIDITY TESTAFTER TEST MEET ITEM 8,940±2ºC 90~95%RH 48 HOURS
13LOAD TESTAFTER TEST MEET ITEM 8,915W 100 HOURS
14MAGNETφ60*24*12 MATERIAL SIZE
15TOTAL FLUXMAX WELL
16FLUX DENSITYGAUSS
17POLARIZATIONWhen a positive DC current is applied to the terminal marked(+),diaphragm shall move forward
18NET WEIGHT285g

Product description

The supplier lists this product as Speaker. Its stated application is Car Speaker etc. The listed model is YD78-15. Supplier-stated function: Micro Speaker. The specifications below reflect the information publicly displayed on the listing. Model NO.: YD78-15. Material: Metal. Sound Frequency: High Pitch.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Full Range Custom Raw Frame Speakers 15W 8ohm 78mm Low Frequency for?

The listed minimum order quantity is 2,000 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Full Range Custom Raw Frame Speakers 15W 8ohm 78mm Low Frequency for cost?

The published price is US$3.00 – 5.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
