Ground Support Headset with Flexible Boom Mic
- Communication
- Wired
- Impedance
- 150 ohms (300 ohms each; wired in parallel)
- Frequency Response
- 100Hz to 8 kHz
- Sensitivity
- 95+/-5 dB SPL
- Jack Diameter
- 6.3mm
- Jack Type
- Avaition Headset Plug
Specifications
| Product name | Ground Support Headset with Flexible Boom Mic |
|---|---|
| Category | Bluetooth & Communication Headsets |
| Customization | Available |
| Wire Material | PU |
| Color | Blue, Red, Black, Green/Gray, Yellow, Orange, Pink |
| Model NO. | PH-200A |
| Type | Electret Earphone |
| Communication | Wired |
| Function | Noise-Canceling |
| Jack Diameter | 6.3mm |
| Jack Type | Avaition Headset Plug |
| Warranty | 12 Months |
| Style | Headband |
| Line-Control | Line-Control |
| Microphone | with Microphone |
| Use | Piloter |
| Product Name | Ground Support Headset with Flexible Boom Mic |
| Transport Package | 1PCS/White Box, Pack All in The Carton |
| Origin | China |
| HS Code | 85183010 |
| Production Capacity | 10, 000PCS/Month |
| Product Descriptions | PH-200 Ground support headset headset Noise canceling headset |
| Straight cord from headset to molded plug | 150CM |
| Noise Reduction Ratings (NRR) | 24dB |
| Frequency Response | 100Hz to 8 kHz |
| Sensitivity | 95+/-5 dB SPL |
| Impedance | 150 ohms (300 ohms each; wired in parallel) |
| Rate Input | 100mW |
| Max. Input | 250mW |
| Element Type | Noise-canceling electret |
| Operating Voltage (supplied by aircraft ) | 8-32 Volts DC |
| Matching Impedance | 150-1000 ohms |
| Operating Temperature | below 20 to 70 °C |
| Cordage | Straight cord from headset to molded |
| Earphone Plug | PJ-055( .25"F6.3 phone plug) |
| Microphone Plug | PJ-068( .206"F5.2 phone plug) |
| Weights | 530g |
| Headset size range Height | 10 to 14 cm |
| Boom | Spring tension boom |
| Price | US$125.00-150.00 50 Pieces(MOQ) |
| Supplier | RAYTALK COMMUNICATIONS LTD |
| Data retrieved | 2026-10-23 |
Available options
| Wire Material | PU |
|---|---|
| Color | |
| Jack Diameter | 6.3mm |
| Impedance | |
| Matching Impedance | 150-1000 ohms |
| Headset size range Height | 10 to 14 cm |
Additional data
| Product Descriptions: | |
|---|---|
| PH-200 Ground support headset headset Noise canceling headset | |
| Ground Support Headset HEADSETS, INTERCOMS AND ACCESSORIES | |
| Overview | |
| PNR Aviation Headset | |
| Plugs | GA Use Dual |
| Super Soft Double Foam Head Pad | |
| New Comfort foam, undercut ear seals | |
| Molded cord assembly made to exceptional pull and flex standards | |
| Noise-canceling electret | |
| Strong Steel Boom provides flexibility and steady microphone placement | |
| Straight cord from headset to molded plug: | 150CM |
| Noise Reduction Ratings (NRR): | 24dB |
| Specifications | |
| Headphone | |
| Type: | Dynamic (F50) |
| Frequency Response: | 100Hz to 8 kHz |
| Sensitivity: | 95+/-5 dB SPL |
| (1 kHz, 1 mW input per earcup side) | |
| full volume on ear simulator | |
| Impedance: | 150 ohms (300 ohms each; wired in parallel) |
| Rate Input: | 100mW |
| Max. Input: | 250mW |
| Microphone and Amplifier: | |
| Element Type: | Noise-canceling electret |
| Frequency Response: | 100Hz to 5 kHz |
| Operating Voltage (supplied by aircraft ): | 8-32 Volts DC |
| Matching Impedance: | 150-1000 ohms |
| Sensitivity: | 33+/4 dB |
| (ref: 0dB SPL=20.0uPa at 1 kHz with 10 Vdc 150 ohms AC load) | |
| General | |
| Operating Temperature: | below 20 to 70 °C |
| Cordage: | Straight cord from headset to molded |
| plug, | 150CM |
| Intercom Connections Plug: | |
| Earphone Plug: | PJ-055( .25"F6.3 phone plug) |
| Microphone Plug: | PJ-068( .206"F5.2 phone plug) |
| Weights: | 530g |
| Headset size range Height: | 10 to 14 cm |
| Color: | Green/Black/Pink/Red/Yellow/Blue/White/Gray |
| Boom: | Spring tension boom |
Product description
The supplier lists this product as Electret Earphone. Its stated application is Piloter. The listed model is PH-200A. Supplier-stated function: Noise-Canceling. The specifications below reflect the information publicly displayed on the listing. Wire Material: PU. Model NO.: PH-200A. Noise Reduction Ratings (NRR): 24dB. Frequency Response: 100Hz to 8 kHz. Sensitivity: 95+/-5 dB SPL. Impedance: 150 ohms (300 ohms each; wired in parallel). Matching Impedance: 150-1000 ohms.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
