Helicopter Pilot Active Noise-Reduction Headset & Noise-Canceling Microphone
- Impedance
- 150 ohms (300 ohms each; wired in parallel)
- Frequency Response
- 100Hz to 8 kHz
- Sensitivity
- 95+/-5 dB SPL
- Style
- Handheld
- Type
- Handheld
- Usage
- Aviation
Specifications
| Product name | Helicopter Pilot Active Noise-Reduction Headset & Noise-Canceling Microphone |
|---|---|
| Category | Call Center, Business & Aviation Headsets |
| Customization | Available |
| Style | Handheld |
| Usage | Aviation |
| Model NO. | PH-100AHC |
| Type | Handheld |
| Battery Type | Small AA Battery |
| Certification | CE, ISO, RoHS |
| Warranty | 12 Months |
| Microphone | with Microphone |
| Function | Noise-Canceling |
| Use | Pilot Use |
| Transport Package | Carton Box |
| Specification | SGS |
| Origin | Shenzhen of China |
| HS Code | 85183010 |
| Production Capacity | 1000PCS/Week |
| Detail Technical Specification | Overview |
| Noise Reduction Ratings (NRR) | 24dB |
| Frequency Response | 100Hz to 8 kHz |
| Sensitivity | 95+/-5 dB SPL |
| Impedance | 150 ohms (300 ohms each; wired in parallel) |
| Rate Input | 100mW |
| Max. Input | 250mW |
| Element Type | Noise-canceling electret |
| Operating Voltage (supplied by aircraft ) | 8-32 Volts DC |
| Matching Impedance | 150-1000 ohms |
| Operating Temperature | -20 to 70°C |
| Cordage | RAN-1000AH Coiled cord from headset |
| Intercom Connections Plug | U174/U |
| Weights | AN-1000H ----570g |
| Attenuation Frequency Band | 20Hz~20KHz |
| Main Attenuation Frequency Band | 20Hz~600Hz |
| Attenuation Capability | 18~21dB |
| Power Consumption | 30 mW |
| Headset size range Height | 10 to 14 cm |
| Package | headset in a carton box. |
| MOQ | 24/pcs |
| Price | US$175.00 24-49 Pieces US$165.00 50+ Pieces |
| Supplier | RAYTALK COMMUNICATIONS LTD |
| Data retrieved | 2026-10-23 |
Available options
| Impedance | |
|---|---|
| Matching Impedance | 150-1000 ohms |
| Power Consumption | 30 mW |
| Headset size range Height | 10 to 14 cm |
Additional data
| Overview | PNR Aviation Headset Helicopter Use U174/U Plug Super Soft Double Foam Head Pad Noise-canceling electret Microphone Strong Steel Boom for perfect microphone placement Easy-to-wear super soft silicone gel ear seals Headband Size Adjustment Coiled cord from headset to molded plug, 70CM Assembled strictly following the FAA TSO standards Noise Reduction Ratings (NRR):24dB |
|---|---|
| Headphone | Type: Dynamic (F50) Frequency Response:100Hz to 8 kHz Sensitivity:95+/-5 dB SPL (1 kHz, 1 mW input per earcup side) full volume on ear simulator Impedance:150 ohms (300 ohms each; wired in parallel) Rate Input:100mW Max. Input: 250mW Microphone and Amplifier: Element Type: Noise-canceling electret Frequency Response:100Hz to 5 kHz Operating Voltage (supplied by aircraft ):8-32 Volts DC Matching Impedance: 150-1000 ohms Sensitivity:-33+/-4 dB (ref: 0dB SPL=20.0uPa at 1 kHz with 10 Vdc 150 ohms AC load) |
| General | Operating Temperature: -20 to 70°C Cordage: RAN-1000AH Coiled cord from headset to molded plug, 70CM Intercom Connections Plug: U174/U Weights: AN-1000H ----570g Noise Reduction Specifications: Attenuation Frequency Band: 20Hz~20KHz Main Attenuation Frequency Band: 20Hz~600Hz Attenuation Capability: 18~21dB Power Consumption: 30 mW Headset size range Height: 10 to 14 cm |
Product description
The supplier lists this product as Handheld. Its stated application is Aviation. The listed model is PH-100AHC. Supplier-stated function: Noise-Canceling. The specifications below reflect the information publicly displayed on the listing. Model NO.: PH-100AHC. Battery Type: Small AA Battery. Noise Reduction Ratings (NRR): 24dB. Frequency Response: 100Hz to 8 kHz. Sensitivity: 95+/-5 dB SPL. Impedance: 150 ohms (300 ohms each; wired in parallel). Matching Impedance: 150-1000 ohms. Attenuation Frequency Band: 20Hz~20KHz. Main Attenuation Frequency Band: 20Hz~600Hz. Power Consumption: 30 mW.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Helicopter Pilot Active Noise-Reduction Headset & Noise-Canceling?
The listed minimum order quantity is 24 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Helicopter Pilot Active Noise-Reduction Headset & Noise-Canceling cost?
The published price is US$165.00 – 175.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
PH-100AHC · US$165.00 – 175.00 · MOQ 24 Pieces
