High Performance Active DSP Line Array Speaker with Built-in Class D Amplifier for Live Music Event/ Concert/ Lecture Hall
- Impedance
- 8 Ohm
- Application
- Commercial, Professional Audio
- Hi-Fi
- Not Hi-Fi
- Activity
- Active
- Operation Mode
- Wire / Remote Control
- Speaker Material
- Wood
Specifications
| Product name | High Performance Active DSP Line Array Speaker with Built-in Class D Amplifier for Live Music Event/ Concert/ Lecture Hall |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Hi-Fi | Not Hi-Fi |
| Model NO. | LAP-350+LSUBA-15DSP |
| Activity | Active |
| Operation Mode | Wire / Remote Control |
| Speaker Material | Wood |
| Application | Commercial, Professional Audio |
| Certification | CE, RoHS |
| Model | Lsuba-15DSP |
| Low Frequency Driver | 15" with 4" Voice Coil |
| Peak Power | 3200 W |
| Frequency Response [-6 Db] | 35 Hz - 200 Hz |
| Impedance | 8 Ohm |
| Max Spl | 136db |
| Directivity | Omnidirectional or Cardioid Selectable |
| DSP Processor | 56-Bit Controller DSP |
| Transport Package | Gift Box/Export Carton/Pallet |
| Origin | Guangdong China |
| HS Code | 8518290000 |
| Production Capacity | 10000 |
| A very good questions | Our advantage is more than 10 years expertise and experience in the commercial audio industry, we are good at listening to my customers, getting to know their need and proposing right solution with reliable products. With support from specialized R&D and proficient production teams, we succeed in offering innovative and sophisticated audio equipment of cutting-edge technology, and always keep in mind that to make our customers win and profitable is the core in business cooperation. |
| Price | US$1,408.00-3,620.00 1 Set(MOQ) |
| Supplier | Guangzhou strong sound electronic equipment Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|---|
| Peak Power | 3200 W |
| Impedance | 8 Ohm |
Additional data
| Model | LAP-350 |
|---|---|
| Model Type | Ferrite Magnet Unit |
| High Frequency Driver | 1.7" voice coil HF driver |
| Low Frequency Drivers | 2 × 6.5" drivers with 2.5" voice coils |
| Frequency Response [-6 dB] | 70 Hz – 20 kHz |
| Nominal Impedance | 8 Ω |
| Maximum SPL | 128 dB |
| Directivity | Horizontal 110° × Vertical 10° |
| Power Rating (RMS) | 350 W |
| Peak Power | 1400 W |
| Enclosure Material | 15 mm multi-ply plywood |
| Handles | 2 (left side) |
| Dimensions (W × H × D) | 532 mm × 210 mm × 320 mm |
| Model | LSUBA-15DSP |
|---|---|
| Low Frequency Driver | 15" with 4" voice coil |
| Frequency Response [-6 dB] | 35 Hz – 200 Hz |
| Nominal Impedance | 8 Ω |
| Maximum SPL | 136 dB |
| Directivity | Omnidirectional or cardioid selectable |
| Peak Power | 3200 W |
| Amplifier Type | Class D |
| DSP Processor | 56-bit Controller DSP |
| AD/DA Converter | 24-bit / 48 kHz |
| System Presets | Music, Live, Flat, Speech, Show |
| Enclosure Material | 15 mm plywood |
| Handles | 4 (left side) |
| Dimensions (W × H × D) | 532 mm × 455 mm × 645 mm |
Product description
The supplier lists this product. Its stated application is Commercial, Professional Audio. The listed model is LAP-350+LSUBA-15DSP. The specifications below reflect the information publicly displayed on the listing. Noise: Na. Model NO.: LAP-350+LSUBA-15DSP. Speaker Material: Wood. Model: Lsuba-15DSP. Low Frequency Driver: 15" with 4" Voice Coil. Peak Power: 3200 W. Frequency Response [-6 Db]: 35 Hz - 200 Hz. Impedance: 8 Ohm.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for High Performance Active DSP Line Array Speaker with Built-in Class D?
The listed minimum order quantity is 1 set. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does High Performance Active DSP Line Array Speaker with Built-in Class D cost?
The published price is US$1,408.00 – 3,620.00 per set. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
LAP-350+LSUBA-15DSP · US$1,408.00 – 3,620.00 · MOQ 1 Set
