High Power 1000W Neo Woofer (18BG1000)
- Power
- 1000W
- Application
- Commercial
- Activity
- Passive
- Magnet
- Neodynium
Specifications
| Product name | High Power 1000W Neo Woofer (18BG1000) |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Activity | Passive |
| Application | Commercial |
| Model NO. | 18BG1000 |
| Power | 1000W |
| Magnet | Neodynium |
| Transport Package | Foam+Carton Packing |
| Origin | China |
| HS Code | 851829000 |
| Production Capacity | 1000PCS Per Month |
| Price | US$110.00-200.00 8 Pieces(MOQ) |
| Supplier | Guangzhou VEMA Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Power | 1000W |
|---|
Additional data
| Model | 18BG1000 |
|---|---|
| Nominal Specifications | |
| Nominal Diameter | 460mm/18 |
| Overall Diameter | 460mm/18 |
| Bolt Circle Diameter | 441-8*6.5mm |
| Baffle Cutout Diameter | 421mm/16.6inch |
| Depth | 210mm/8.3inch |
| Flange and Gasket Thickness | 14mm/0.6inch |
| Net Weight | 9.7KGS |
| Shipping Box | 47*47*23Cm |
| (Single Carton Box) | 1pcs/Carton |
| Shipping Weight | 12KGS |
| Electrical Specifications | |
| Minimum Impedance | 5.38OHMS |
| Nominal Impedance | 8OHMS |
| Nominal Power Handling *** | 800WATTS |
| Maximum Power Handling **** | 1600WATTS |
| Sensitivity (1W/1m) | 97.2 dB |
| Frequency Range | 37.2-1500Hz |
| Voice Coil Diameter | 99.3mm/4inch |
| Winding Material | COPPER IN/OUT |
| Former Material | TIL |
| Winding Depth | 25MM |
| Magnetic Gap Depth | 12MM |
| Flux Density | 1.2T |
| Thiele & Small Parameters | |
| Fs | 37.2 HZ |
| Re | 5.3 OHMS |
| Bl | 25.583 |
| Cms | 94.546 |
| Rms | |
| Qes | 0.366 |
| Qms | 11.701 |
| Qts | 0.355 |
| Vas | 243.283 umM3 |
| Sd | 134.614 mM2 |
| Xmax * | 6.5MM |
| Xdamage ** | 23 MM |
| Le | 0.41 |
| Eta Zero | 3.31% |
Product description
The supplier lists this product. Its stated application is Commercial. The listed model is 18BG1000. The specifications below reflect the information publicly displayed on the listing. Model NO.: 18BG1000. Power: 1000W.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for High Power 1000W Neo Woofer (18BG1000)?
The listed minimum order quantity is 8 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does High Power 1000W Neo Woofer (18BG1000) cost?
The published price is US$110.00 – 200.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
