High Power 220mm Magnet 4″ Voice Coil 15 Inch Speaker
Crossovers, Voice Coils, Cones & Repair Parts

High Power 220mm Magnet 4″ Voice Coil 15 Inch Speaker

Model: EL15-A Customization available Speaker Parts & Accessories
US$61.901–99 Pieces
US$56.90100–999 Pieces
US$51.901,000+ Pieces
MOQ 1 Pieces
Nominal Diameter
380mm/15 Inch
Nominal Impedance
8 Ohm
AES Power Handing
500W
Sensitivity 1W/1m
97dB
Frequency Range
44-2.9kHz
Send Inquiry Full specifications

Specifications

Product nameHigh Power 220mm Magnet 4″ Voice Coil 15 Inch Speaker
CategoryCrossovers, Voice Coils, Cones & Repair Parts
CustomizationAvailable
Nominal Diameter380mm/15 Inch
Nominal Impedance8 Ohm
Model NO.EL15-A
AES Power Handing500W
Sensitivity 1W/1m97dB
Frequency Range44-2.9kHz
Transport PackageCarton
Specification394*167
OriginChina
HS Code85182900
Production Capacity100000 PCS/Year
PriceUS$61.90 1-99 Pieces US$56.90 100-999 Pieces US$51.90 1,000+ Pieces
SupplierMeirui (Guangdong) Audio Equipment Co., Ltd.
Data retrieved2026-10-23

Available options

Nominal Diameter380mm/15 Inch
AES Power Handing500W
Nominal Impedance8 Ohm

Additional data

General Specifications
Nominal Diameter380mm/15 inch
Nominal Impedance8Ω
AES Power Handing500W (AES)
Maximum Power800W
Sensitivity 1W/1M97dB
Frequency Range44-2.9kHz
Voice Coil Diameter99.5mm/4 inch
Windinig MaterialCapper
Former Materialkapton
Winding Depth19mm
surround materialPolycotton
surround DesignTriple-roll
MagnetΦ220Ferrite Ring
Thiele & Small Parameters
Resonance FrequencyFs44Hz
DC ResistanceRe5.2Ω
Mechanical FactorQms20.96
Electrical FactorQes0.4
Total FactorQts0.39
BL FactorBL24T.m
Effective Moving MassMms163g
ComplianceCms81μ M/N
Equivalent Cas Air LoadVas94L
Effettive Piston AreaSd908cm²
η(Eta Zero)η01.9%
Mountiong & Shipping Information
Overall Diameter394mm
Bolt circle diameter373mm
Baffle Cutout Diameter353mm
Depth167mm
Net Weight11.3kg
Shipping Weight11.8kg
Shipping Box(Single)39.5*39.5*18cm

Product description

The supplier lists this product. The listed model is EL15-A. The specifications below reflect the information publicly displayed on the listing. Nominal Impedance: 8 Ohm. Model NO.: EL15-A. AES Power Handing: 500W. Sensitivity 1W/1m: 97dB. Frequency Range: 44-2.9kHz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for High Power 220mm Magnet 4″ Voice Coil 15 Inch Speaker?

The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does High Power 220mm Magnet 4″ Voice Coil 15 Inch Speaker cost?

The published price is US$51.90 – 61.90 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
