High Quality 2X0.5mm CCA Conductor Transparent Speaker Cable
- Type
- Coaxial
- Application
- Multimedia, Speaker, Computer, Monitor
- Color
- Red
- Species
- VGA
- Connector
- RCA
- Material Shape
- Flat Wire
Specifications
| Product name | High Quality 2X0.5mm CCA Conductor Transparent Speaker Cable |
|---|---|
| Category | Speaker Wire & Speaker Cables |
| Model NO. | speaker cable |
| Type | Coaxial |
| Species | VGA |
| Connector | RCA |
| Material Shape | Flat Wire |
| Wire Core Material | Bare Copper Wire |
| Certification | RoHS, CE, CCC |
| Brand | Fuu |
| Use | for Speaker system |
| Transport Package | Coil, Wooden Reel, Plastic Reel and Paper Reel |
| Specification | Speaker Cable |
| Origin | Made in China |
| Production Capacity | 200000km/Year |
| Customization | Available |
| Application | Multimedia, Speaker, Computer, Monitor |
| Color | Red |
| CHARACTERISTIC | 1) Different series of zips and twist wires |
| a) Packing lengths | 100m/roll, 200m/roll, 305m/roll |
| b) Inner packing | wooden drum, plastic drum, paper drum |
| c) Outer packing | carton box, pull out box |
| Rip Cord | Synthetic Fiber |
| Shield | AI/PET Foil |
| Optional Drain Wire | Solid Or Stranded Bare Copper |
| Jacket | PVC or LSZH |
| Our Service | 1) Quick Response --All inquiries will be replied within 24 hours. |
| Price | US$0.30 10,000 Meters (MOQ) |
| Supplier | Hangzhou Spring Electronics Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Material Shape | Flat Wire |
|---|---|
| Wire Core Material | Bare Copper Wire |
| Color | Red |
| Connector | RCA |
| a) Packing lengths |
Additional data
| Color- Coded PE/PVC Insulation | |||||||
|---|---|---|---|---|---|---|---|
| Insulation Wraped with or without Polyester Tape | |||||||
| Rip Cord: Synthetic Fiber | |||||||
| Shield: AI/PET Foil | |||||||
| Optional Drain Wire: Solid Or Stranded Bare Copper | |||||||
| Jacket: PVC or LSZH | |||||||
| PE/PVC Insulated & PVC Jacketed Un-shielded Alarm Cable | |||||||
| C.S.Area | Construction | Insulation | Jacket | Overall | |||
| (mm2) | Core x No./Dia. | Thickness(mm) | Thickness(mm) | Diameter(mm) | |||
| 2*0.22 | 2*7/0.20 | 0.2 | 0.7 | 3.9 | |||
| 4*0.22 | 4*7/0.20 | 4.4 | |||||
| 6*0.22 | 6*7/0.20 | 5.0 | |||||
| 8*0.22 | 8*7/0.20 | 5.4 | |||||
| 10*0.22 | 10*7/0.20 | 6.2 | |||||
| 12*0.22 | 12*7/0.20 | 6.4 | |||||
| 14*0.22 | 14*7/0.20 | 6.6 | |||||
| 16*0.22 | 16*7/0.20 | 7.4 | |||||
| 20*0.22 | 20*7/0.20 | 7.8 | |||||
| 2*0.20 | 2*1/0.50 | 0.2 | 0.7 | 3.1 | |||
| 4*0.20 | 4*1/0.50 | 3.6 | |||||
| 6*0.20 | 6*1/0.50 | 4.2 | |||||
| 8*0.20 | 8*1/0.50 | 4.6 | |||||
| 10*0.20 | 10*1/0.50 | 5.3 | |||||
| 12*0.20 | 12*1/0.50 | 5.5 | |||||
| 14*0.20 | 14*1/0.50 | 5.9 | |||||
| 16*0.20 | 16*1/0.50 | 6.3 | |||||
| 20*0.20 | 20*1/0.50 | 6.9 | |||||
| 2*0.28 | 2*1/0.60 | 0.2 | 0.7 | 3.9 | |||
| 4*0.28 | 4*1/0.60 | 4.5 | |||||
| 6*0.28 | 6*1/0.60 | 5.0 | |||||
| 8*0.28 | 8*1/0.60 | 5.7 | |||||
| 10*0.28 | 10*1/0.60 | 6.0 | |||||
| 12*0.28 | 12*1/0.60 | 6.4 | |||||
| 14*0.28 | 14*1/0.60 | 6.8 | |||||
| 16*0.28 | 16*1/0.60 | 7.6 | |||||
| 20*0.28 | 20*1/0.60 | 8.2 | |||||
| PE/PVC Insulated & PVC Jacketed Un-shielded Security Alarm Cable with Power Cords | |||||||
| C.S.Area | Construction | Insulation | Jacket | C.S.Area | Construction | O.D. | Overall |
| (mm2) | Core x No./Dia. | Thickness(mm) | Thickness(mm) | (mm2) | Core x No./Dia. | (mm) | Diameter(mm) |
| 2*0.22 | 2*7/0.20 | 0.2 | 0.7 | 2*0.50 | 2*16/0.2 | 1.6 | 5.4 |
| 4*0.22 | 4*7/0.20 | 6 | |||||
| 6*0.22 | 6*7/0.20 | 6.4 | |||||
| 8*0.22 | 8*7/0.20 | 7.2 | |||||
| 10*0.22 | 10*7/0.20 | 7.5 | |||||
| 12*0.22 | 12*7/0.20 | 7.6 | |||||
| 2*0.22 | 2*7/0.20 | 0.2 | 0.7 | 2*0.75 | 2*24/0.2 | 1.8 | 6.0 |
| 4*0.22 | 4*7/0.20 | 6.6 | |||||
| 6*0.22 | 6*7/0.20 | 7.0 | |||||
| 8*0.22 | 8*7/0.20 | 7.8 | |||||
| 10*0.22 | 10*7/0.20 | 8.0 | |||||
| 12*0.22 | 12*7/0.20 | 8.2 | |||||
| *Above charter shows only the typical cables, customized order are also welcome! |
Product description
The supplier lists this product as Coaxial. Its stated application is for Speaker system. The listed model is speaker cable. The specifications below reflect the information publicly displayed on the listing. Model NO.: speaker cable. Connector: RCA. Material Shape: Flat Wire. Wire Core Material: Bare Copper Wire.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for High Quality 2X0.5mm CCA Conductor Transparent Speaker Cable?
The listed minimum order quantity is 10,000 meters. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does High Quality 2X0.5mm CCA Conductor Transparent Speaker Cable cost?
The published price is US$0.30 per meter. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
speaker cable · US$0.30 · MOQ 10,000 Meters
