High Quality 3″ Voice Coil Professional Hf Tweter PRO Audio Speaker High Frequency Neodymium Compression Driver High Quality Professional Tweeter
- Application
- Commercial
- Web
- fdbaudiochina.en.made-in-china.com
Specifications
| Product name | High Quality 3″ Voice Coil Professional Hf Tweter PRO Audio Speaker High Frequency Neodymium Compression Driver High Quality Professional Tweeter |
|---|---|
| Category | Crossovers, Voice Coils, Cones & Repair Parts |
| Customization | Available |
| Application | Commercial |
| Transport Package | Carton Box |
| Model NO. | PT3036NA |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 5000PCS/Month |
| Specifications | Exit Throat Diameter |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Web | fdbaudiochina.en.made-in-china.com |
| Price | US$122.00-970.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Additional data
| Exit Throat Diameter | 36/1.4 mm/inch |
|---|---|
| Rated Impedance | 8 ohm |
| Sensitivity 1W,1M,on H2501 horn | 110 dB |
| Frequency Range | 500-20000 Hz |
| Diaphragm Material | Pure Titanium |
| Suspension Material | Mylar |
| Voice Coil Diameter | 74.4/3 mm/inch |
| Voice Coil Material | Edgewound Aluminum |
| Number of Layers | 1-Outside |
| Flux Density | 1.9 T |
| Magnetics | Neodymium |
| Overall Diameter | 131 mm |
| Overall Height | 58 mm |
| Net Weight | 2.4 kg |
| Shipping Weight | 2.5 kg |
Product description
The supplier lists this product. Its stated application is Commercial. The listed model is PT3036NA. The specifications below reflect the information publicly displayed on the listing. Model NO.: PT3036NA.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for High Quality 3″ Voice Coil Professional Hf Tweter PRO Audio Speaker?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does High Quality 3″ Voice Coil Professional Hf Tweter PRO Audio Speaker cost?
The published price is US$122.00 – 970.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
PT3036NA · US$122.00 – 970.00 · MOQ 1 Piece
