Hot Sale 1.75” Ferrite Compression High Driver, Tweeter High Driver Loudspeaker.
Speaker Drivers, Woofers & Tweeters

Hot Sale 1.75” Ferrite Compression High Driver, Tweeter High Driver Loudspeaker.

Model: DE4428T Customization available Speaker Parts & Accessories
US$5.00 – 15.00
MOQ 12 Pieces
Impedance
8 Ohm
Sensitivity
107dB
Application
Stage
Operation Mode
No
Speaker Material
Plastic
Certification
CE, RoHS, FCC
Send Inquiry Full specifications

Specifications

Product nameHot Sale 1.75” Ferrite Compression High Driver, Tweeter High Driver Loudspeaker.
CategorySpeaker Drivers, Woofers & Tweeters
Model NO.DE4428T
Operation ModeNo
Speaker MaterialPlastic
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating50 W
Program Power100 W
Frequency Range1200-18000Hz
Sensitivity107dB
Voice Coil1.75''vc
Coil MaterialAluminum
FormerKapton
Diaphragm MaterialTitanium
Impedance8 Ohm
MagnetFerrite
Transport PackageCarton
Specification425 x 270 x 140 mm
OriginChina
HS Code8518290000
Production Capacity50000
CustomizationAvailable
ActivityPassive
PriceUS$5.00-15.00 12 Pieces (MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

Speaker MaterialPlastic
AES Power Rating50 W
Program Power100 W
Coil MaterialAluminum
Diaphragm MaterialTitanium
Impedance8 Ohm

Additional data

Throat diametermm(in.)25.4(1)
Nominal impedanceΩ8
DC resistanceRe Ω6
Program power (1)W100
AES Power rating(2)W50
Sensitivity (3)dB107
Frequency rangeHz1200 ~ 18000
Voice coil diametermm(in.)44(1.75)
Magnet materialFerrite
Magnet ODmm120
Coil materialCCAW
Former materialKapton
Diaphragm materialTitanium
Voice coil InductancemH0.08
Flux densityT1.4
Recommended crossover (4)Hz1500
Net weightKg1.5
Multipack size(12) (WxDxH)mm425 x 270 x 140
Multipack weightKg19.1(12PCS)

Product description

The supplier lists this product. Its stated application is Stage. The listed model is DE4428T. The specifications below reflect the information publicly displayed on the listing. Model NO.: DE4428T. Speaker Material: Plastic. AES Power Rating: 50 W. Program Power: 100 W. Frequency Range: 1200-18000Hz. Sensitivity: 107dB. Coil Material: Aluminum. Diaphragm Material: Titanium. Impedance: 8 Ohm. Noise: 0.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Hot Sale 1.75” Ferrite Compression High Driver, Tweeter High Driver?

The listed minimum order quantity is 12 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Hot Sale 1.75” Ferrite Compression High Driver, Tweeter High Driver cost?

The published price is US$5.00 – 15.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
