Huain Ms1212 DSP Digital Matrix Audio Conferencing System
- Type
- Digital Audio Conferencing System
- Color
- Black
- Audio Quality
- HD Audio Quality
- Communication Mode
- Wired
- OEM Custom
- Accept
- ODM Custom
- Accept
Specifications
| Product name | Huain Ms1212 DSP Digital Matrix Audio Conferencing System |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Customization | Available |
| Audio Quality | HD Audio Quality |
| Color | Black |
| Model NO. | HY-MS1212 |
| Communication Mode | Wired |
| Type | Digital Audio Conferencing System |
| OEM Custom | Accept |
| ODM Custom | Accept |
| Sample | Accept |
| Logo Custom | Accept |
| Function Custom | Accept |
| Transport Package | Carton |
| Origin | China |
| HS Code | 8518100000 |
| Production Capacity | 1000PCS/Month |
| Price | US$99.00 1-49 unit US$93.00 50-119 unit US$86.00 120+ unit |
| Supplier | Huain (Zhuhai) Digital Technology Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Color | Black |
|---|---|
| OEM Custom | Accept |
| ODM Custom | Accept |
| Logo Custom | Accept |
| Function Custom | Accept |
Additional data
| Technical Specifications | |
|---|---|
| System Capacity | 30 units per channel, expandable to 76,800 units |
| Microphone Type | Cardioid condenser, 9.7mm gold-plated cartridge |
| Frequency Response | 20Hz~20KHz |
| Output Impedance | <200Ω |
| Signal-to-Noise Ratio | >90dB |
| Dynamic Range | >96dB |
| Total Harmonic Distortion | <0.05% |
| Microphone Sensitivity | -37dB±2dB |
| Connection Method | Junction box, T-connector |
| Connection Cable | 8-pin DIN interface, RJ45 interface (optional) |
| Units Open Simultaneously | 1-6 or all |
| ID Function | Customizable ID |
| Equivalent Noise | 18dBA (SPL) |
| Max SPL | 125dB (THD<3%) |
| Chairman Units | 8 units |
| VIP Units | 8 units |
| Color | Gray |
| Installation Method | Desktop |
| Power Parameters | |
| Input Power | DC 24V±5% |
| Input Current | 60mA±5% |
| Power Consumption | 1.5W |
| Physical Parameters | |
| Microphone Stem Dimensions | 390mm |
| Base Dimensions | 100×130×38mm (without microphone stem) |
| Package Dimensions | 550×220×93mm |
| Net/Gross Weight | 0.95Kg/approx. 1.73Kg |
| Product Accessories (subject to actual items) | |
| T-Connector | 1 pc |
| Extension Cable | 1 pc |
| Foam Windscreen | 1 pc |
| Warranty Card | 1 copy |
| Certificate of Conformity | 1 copy |
Product description
The supplier lists this product as Digital Audio Conferencing System. The listed model is HY-MS1212. The specifications below reflect the information publicly displayed on the listing. Model NO.: HY-MS1212.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Huain Ms1212 DSP Digital Matrix Audio Conferencing System?
The listed minimum order quantity is 1 unit. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Huain Ms1212 DSP Digital Matrix Audio Conferencing System cost?
The published price is US$86.00 – 99.00 per unit, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
HY-MS1212 · US$86.00 – 99.00 · MOQ 1 unit
