Ka-1 Birch Plywood Line Array Dual 15″ Passive Speaker Neodymium Driver
- Application
- Commercial, Home
- Activity
- Passive
- Operation Mode
- Wire / Remote Control
- Speaker System
- Optional Combination
- Speaker Material
- Wood
- Certification
- CE, RoHS
Specifications
| Product name | Ka-1 Birch Plywood Line Array Dual 15″ Passive Speaker Neodymium Driver |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Activity | Passive |
| Operation Mode | Wire / Remote Control |
| Model NO. | KA-1 |
| Speaker System | Optional Combination |
| Speaker Material | Wood |
| Application | Commercial, Home |
| Certification | CE, RoHS |
| Max Spl | 147dB |
| Frequency Response(-3dB) | 35Hz-20kHz |
| Cabinet | First Grade Russian Birch Plywood |
| Components | Lf: 2X15" Mf: 4X6.5" Hf: 3X3" |
| Power Handling | Lf: 2 X 600W Mf: 600W Hf: 220W |
| Speaker | Neodymium Magnet |
| Transport Package | Strong Wooden Frame and Carton |
| Specification | 134x44x52cm (WxHxD) |
| Origin | Guangdong Province, China |
| HS Code | 85182200 |
| Production Capacity | 1000 Units/ Month |
| Package Size | 134.00cm * 44.00cm * 52.00cm |
| Package Gross Weight | 106.000kg |
| Horizontal | 90° symmetric |
| vertical | dependent upon the number of elements and the line source curvature |
| LF | 2 × 15″ neodymium |
| MF | 4 × 6.5″ neodymium, direct-radiating |
| HF | 3× 3″ diaphragm compression drivers |
| IN | 1 x 8-point PA-COM |
| LINK | 1 x 8-point PA-COM |
| inter-enclosure angles | 0°, 0.5°, 1°, 1.5°, 2°, 2.5°, 3°, 4° or 5° |
| Price | US$1,000.00-2,000.00 1 Piece(MOQ) |
| Supplier | Guangzhou Xinbaosheng Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|---|
| Power Handling | Lf: 2 X 600W Mf: 600W Hf: 220W |
Additional data
| Type | K1 3 way audio line array system |
|---|---|
| Usable bandwidth (-10 dB) | 35 Hz - 20 kHz ([K1]) |
| Maximum SPL1 | 149 dB ([K1]) |
| Nominal directivity (-6 dB) | Horizontal: 90° symmetric |
| vertical: dependent upon the number of elements and the line source curvature | |
| Transducers | LF: 2 × 15″ neodymium |
| MF: 4 × 6.5″ neodymium, direct-radiating | |
| HF: 3× 3″ diaphragm compression drivers | |
| Acoustical load | LF: bass-reflex; MF: bass-reflex; HF: DOSC waveguide |
| Nominal impedance | LF: 2 × 8 Ω; MF: 8 Ω ; HF: 8 Ω |
| Connectors | IN: 1 x 8-point PA-COM LINK: 1 x 8-point PA-COM |
| Rigging and handling | 4 handles integrated into the cabinet |
| inter-enclosure angles: 0°, 0.5°, 1°, 1.5°, 2°, 2.5°, 3°, 4° or 5° | |
| Cabinet | First grade Russian birch plywood, high density polyethylene Front steel grill with anti-corrosion coating acoustically neutral 3D fabric |
| Rigging components | High grade steel with anti-corrosion coating |
| Finish | Dark Gray brown Pantone 426C |
| Dimension | 134x44x52cm (WxHxD) |
| Weight (net) | 106 kg / 234 lb |
Product description
The supplier lists this product. Its stated application is Commercial, Home. The listed model is KA-1. The specifications below reflect the information publicly displayed on the listing. Model NO.: KA-1. Speaker Material: Wood. Frequency Response(-3dB): 35Hz-20kHz. Power Handling: Lf: 2 X 600W Mf: 600W Hf: 220W.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Ka-1 Birch Plywood Line Array Dual 15″ Passive Speaker Neodymium?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Ka-1 Birch Plywood Line Array Dual 15″ Passive Speaker Neodymium cost?
The published price is US$1,000.00 – 2,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
KA-1 · US$1,000.00 – 2,000.00 · MOQ 1 Piece
