Ka-2 Neodymium Speaker Line Array 3-Way Double 12 Inch Passive Speaker
- Application
- Commercial, Home
- Speaker Material
- Wood
- Certification
- CE, RoHS
- Max Spl
- 147 dB
- Lf
- 2 X 12",450W,2×8Ω
- Mf
- 4 X 6.5",320W,8Ω
Specifications
| Product name | Ka-2 Neodymium Speaker Line Array 3-Way Double 12 Inch Passive Speaker |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Model NO. | KA-2 |
| Speaker Material | Wood |
| Application | Commercial, Home |
| Certification | CE, RoHS |
| Max Spl | 147 dB |
| Lf | 2 X 12",450W,2×8Ω |
| Mf | 4 X 6.5",320W,8Ω |
| Hf | 2 X 3",160W,16Ω |
| Cabinet | First Grade Russian Birch Plywood |
| Impedence | Lf: 2X8 Ohms Mf: 8 Onms Hf: 16 Ohms |
| Transport Package | Strong Wooden Frame and Carton |
| Origin | Guangdong Province, China |
| HS Code | 85182200 |
| Production Capacity | 1000 Units/ Month |
| Customization | Available |
| Operation Mode | Wire / Remote Control |
| Speaker System | Optional Combination |
| Horizontal | 110° / 70° symmetric ; 90° asymmetric |
| Vertical | depends on the number of elements and array curvature. |
| Inter-enclosure angles | 0.25, 1, 2, 3, 4, 5, 7.5 or 10° |
| Feature | KA-2 dual 12inch 3 way audio line array system |
| Rigging components | high grade steel with anti-corrosion coating. |
| Price | US$1,500.00 1 Piece (MOQ) |
| Supplier | Guangzhou Xinbaosheng Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|
Additional data
| Type | KA-2 line array 3-way, dual 12" |
|---|---|
| Usable bandwidth (-10 dB) | 35 Hz - 20 KHz |
| Maximum SPL1 | 147 dB |
| Nominal directivity (-6 dB) | Horizontal : 110° / 70° symmetric ; 90° asymmetric (35°/55° or 55°/33°) |
| Vertical : depends on the number of elements and array curvature. | |
| Transducers | LF: 2 × 12″ cone drivers |
| MF: 4 × 6.5″ cone drivers | |
| HF: 2 × 3″ diaphragm compression drivers | |
| Acoustical load | LF: Bass-reflex, Progressive vent design |
| MF: Bass-reflex ; HF: Waveguide | |
| Nominal impedance | LF : 2 x 8 Ω;MF : 8Ω ; HF : 16Ω |
| Connectors | 2 x 8-point PA-COM |
| Rigging and handling | Captive 4-points rigging system |
| 2 large side handles | |
| Inter-enclosure angles : 0.25, 1, 2, 3, 4, 5, 7.5 or 10° | |
| Cabinet | First grade Russian birch plywood, high density polyethylene Front steel grill with anti-corrosion coating acoustically neutral 3D fabric |
| Finish | Dark Gray brown |
| Dimension | 1338 x 354/286 x 400 mm 52.7 x 14/11.3 x 15.8 in |
| Weight (net) | 56kg / 123lb |
Product description
The supplier lists this product. Its stated application is Commercial, Home. The listed model is KA-2. The specifications below reflect the information publicly displayed on the listing. Model NO.: KA-2. Speaker Material: Wood.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Ka-2 Neodymium Speaker Line Array 3-Way Double 12 Inch Passive Speaker?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Ka-2 Neodymium Speaker Line Array 3-Way Double 12 Inch Passive Speaker cost?
The published price is US$1,500.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
KA-2 · US$1,500.00 · MOQ 1 Piece
