Line Array Speaker PRO Audio System 10” Neodymium Loudspeaker, Powered Speaker Professional Soud System.
PA, Stage & Line-Array Speakers

Line Array Speaker PRO Audio System 10” Neodymium Loudspeaker, Powered Speaker Professional Soud System.

Model: 10NDF65U1 Customization available Speakers & Audio Systems
US$20.00 – 49.00
MOQ 1 Piece
Impedance
8 Ohm
Sensitivity
96 dB
Application
Stage
Activity
Passive
Operation Mode
No
Certification
CE, RoHS, FCC
Send Inquiry Full specifications

Specifications

Product nameLine Array Speaker PRO Audio System 10” Neodymium Loudspeaker, Powered Speaker Professional Soud System.
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
ActivityPassive
Model NO.10NDF65U1
Operation ModeNo
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating350 W
Program Power700 W
Frequency Range65-4000Hz
Voice Coil2.5''vc Ccaw in/out
Sensitivity96 dB
Impedance8 Ohm
MagnetNeodymium
ChassisAluminum
Transport PackageCarton
Specification280 x 280 x 154 mm
OriginChina
HS Code8518290000
Production Capacity50000
PriceUS$20.00-49.00 1 Piece(MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

AES Power Rating350 W
Program Power700 W
Impedance8 Ohm

Additional data

Nominal diametermm (in.)262(10)
Nominal impedanceΩ8
Minimum impedanceΩ6.8
Program power (1)W700
AES Power rating(2)W350
Sensitivity (3)dB96
Frequency rangeHz65 ~ 4000
Voice coil diametermm (in.)65(2.5)
Chassis materialAluminum
Magnet materialNeodymium
Magnet dimensions (ODxIDxh)mm64 x 10 x 10
Coil materialCCAW
Former materialGlass Fiber
Xmax(4)mm6
Xmech(5)mm10
Gap heightmm8
Voice coil Wingding heightmm16
DC resistanceReOhm5.2
Resonance frequencyFsHz65
Moving massMmsg38
ComplianceCmsmm/N0.15
Force factorBLN/A16.8
Mechanical Q-factorQms2.7
Electrical Q-factorQes0.39
Total Q-factorQts0.34
Equivalent air volumeVasI31
Voice coil InductanceLemH0.9
Diaphragm areaSdcm²346
Reference efficiencyEta 0%2.1
Net weightKg3.5
Multipack size (1) (W x D x H)mm280 x 280 x 154
Multipack weightKg4

Product description

The supplier lists this product. Its stated application is Stage. The listed model is 10NDF65U1. The specifications below reflect the information publicly displayed on the listing. Noise: 0. Model NO.: 10NDF65U1. AES Power Rating: 350 W. Program Power: 700 W. Frequency Range: 65-4000Hz. Sensitivity: 96 dB. Impedance: 8 Ohm.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Line Array Speaker PRO Audio System 10” Neodymium Loudspeaker,?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Line Array Speaker PRO Audio System 10” Neodymium Loudspeaker, cost?

The published price is US$20.00 – 49.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
