Nde-14c Hf Car Audio Speaker Driver
- Material
- Aluminum
- Type
- Speaker
- Color
- Black
- Speaker Design
- Driver
- Shape
- Spiral
- Voltage
- 12V
Specifications
| Product name | Nde-14c Hf Car Audio Speaker Driver |
|---|---|
| Category | Car Speakers & Subwoofers |
| Model NO. | NDE-14C |
| Type | Speaker |
| Speaker Design | Driver |
| Shape | Spiral |
| Material | Aluminum |
| Voltage | 12V |
| Current | 3A |
| Energy Exchanging Mechanism | Electrical |
| Magnet | Neo |
| Color | Black |
| Brand | Asm |
| Basket Material | Iron |
| Transport Package | White Box Package |
| Specification | CE |
| Origin | China |
| HS Code | 315000 |
| Production Capacity | 5000PCS/Month |
| Customization | Available |
| After-sales Service | Asm |
| Warranty | One Year |
| Who we are | Ningbo ASM manufacturing, has become one of the largest company specialized in Sub- woofer, Car speaker, ceiling speaker, boom box, Professional sound. Manufacture in China. |
| The reason to work with Ningbo ASM manufacturing | 1) Focus on every detail |
| You can see us at 3 Tradeshows we will attend | NAMM IN January |
| Model No | NDE-12C |
| Throat Diameter | 1 in (25mm) |
| Mounting Type | Screw on |
| Nominal Impedance | 8 Ohm |
| Power Capacity | 30Watts RMS |
| Sensitivity(1W/1M) | 106dB |
| Frequency Range | 1.5KHz-20KHz |
| Diaphragm Material | Titanium |
| Flux Density | 1.45T |
| Overall DiameterxDepth | 80mm(3.15in) |
| Net Weight | 0.83 Kgs |
| Price | Negotiable 500 Pieces (MOQ) |
| Supplier | Ningbo ASM Electronics Technology Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Material | Aluminum |
|---|---|
| Voltage | 12V |
| Color | Black |
| Basket Material | Iron |
| Throat Diameter | 1 in (25mm) |
| Nominal Impedance | 8 Ohm |
Additional data
| Model No: | NDE-12C | NDE-13C | NDE-14C | NDE-15C | NDE-16C |
|---|---|---|---|---|---|
| Throat Diameter: | 1 in (25mm) | 1 in (25mm) | 1 in (25mm) | 1 in (25mm) | 1 in (25mm) |
| Mounting Type: | Screw on 13/8" or Bolt-on | Screw on 1 3/8" or Bolt-on | Screw on 1 3/8" or Bolt-on | Screw on 13/8" or Bolt-on | Screw on 1 3/8" or Bolt-on |
| Nominal Impedance: | 8 Ohm | 8 Ohm | 8 Ohm | 8 Ohm | 8 Ohm |
| Power Capacity: | 30Watts RMS | 40Watts RMS | 60Watts RMS | 100Watts RMS | 120Watts RMS |
| Sensitivity(1W/1M): | 106dB | 107dB | 108dB | 109dB | 110dB |
| Frequency Range: | 1.5KHz-20KHz | 1.2KHz-20KHz | 1.2KHz-20KHz | 1.0KHz-20KHz | 500Hz-20KHz |
| Diaphragm Material: | Titanium | Titanium | Titanium | Titanium | Titanium |
| Voice Coil Diameter | 1.1in(28mm) | 1.35 in(34.4mm) | 1.75 in(44.4mm) | 2.03 in(51.6mm) | 2.84 in(72.2mm) |
| Voice Coil Material | Round& Ribbon Aluminum Wire | Round& Ribbon Aluminum Wire | Round& Ribbon Aluminum Wire | Round& Ribbon Aluminum Wire | Round& Ribbon Aluminum Wire |
| Flux Density: | 1.45T | 1.5T | 1.6T | 1.75T | 1.9T |
| Magnet: | Strontium Ferrite | StrontiumFerrite | Strontium Ferrite | Strontium Ferrite | Strontium Ferrite |
| Overall DiameterxDepth: | 80mm(3.15in) x63mm(2.48in) | 90mm(3.54in) x62.5mm(2.46in) | 115mm(4.53in) x67.5mm(2.66in) | 134mm(5.28in) x79.5mm(3.13in) | 170mm(6.7in) x72.5mm(2.85in) |
| Net Weight: | 0.83 Kgs | 0.95 Kgs | 1.58 Kgs | 2.83 Kgs | 5.36 Kgs |
Product description
The supplier lists this product as Speaker. The listed model is NDE-14C. The specifications below reflect the information publicly displayed on the listing. Model NO.: NDE-14C. Material: Aluminum. Basket Material: Iron. Model No: NDE-12C. Nominal Impedance: 8 Ohm. Power Capacity: 30Watts RMS. Sensitivity(1W/1M): 106dB. Frequency Range: 1.5KHz-20KHz. Diaphragm Material: Titanium.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Nde-14c Hf Car Audio Speaker Driver?
The listed minimum order quantity is 500 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Nde-14c Hf Car Audio Speaker Driver cost?
The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
NDE-14C · Price on request · MOQ 500 Pieces
