Network Remote Control 3X6 Channel Professional 1u Rackmount Digital Audio Processor
- Power
- AC 220 V - 50 Hz
- Frequency response
- 20 Hz – 20 kHz ±1 dB
- Application
- Commercial, Home
- Noise
- ≥105dB
- Hi-Fi
- Hi-Fi
- Activity
- Passive
Specifications
| Product name | Network Remote Control 3X6 Channel Professional 1u Rackmount Digital Audio Processor |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Customization | Available |
| Noise | ≥105dB |
| Hi-Fi | Hi-Fi |
| Model NO. | MA-306 |
| Activity | Passive |
| Operation Mode | Button Control |
| Speaker System | Optional Combination |
| Speaker Material | Metal |
| Application | Commercial, Home |
| Certification | CCC |
| Monitor | LCD Screen |
| THD | >0.01% |
| Operating Temperature | -10 °C to +60 °C |
| PC Interfaces | Rj-45, USB, RS-485 |
| Channel Crosstalk | < -100 Db @ 1 kHz |
| Power | AC 220 V - 50 Hz |
| Transport Package | Carton |
| Specification | 482 × 44.5 × 265 mm |
| Origin | China |
| Package Size | 50.00cm * 50.00cm * 30.00cm |
| Package Gross Weight | 3.500kg |
| Lead Time | 7 days (1 - 1 set) To be negotiated ( > 1 set) |
| Built-in generator | sine, pink & white noise. |
| DSP chip | 32-bit fixed/floating-point |
| Audio latency | < 2 ms |
| D/A conversion | 24-bit |
| Sampling rate | 96 kHz |
| Inputs | 2 / 3 / 4-channel options |
| Audio connector | XLR |
| Input impedance | 10 kΩ |
| Max input level | +14 dBu |
| Input delay | 0 – 500 ms per channel |
| Functions per channel | noise gate, compressor, HP/LP filters, 7-band PEQ |
| Signal generator | sine, pink, white noise |
| Outputs | 4 / 6 / 8-channel options |
| Output impedance | 100 Ω |
| Max output level | +14 dBu |
| Output delay | 0 – 500 ms per channel |
| Frequency response | 20 Hz – 20 kHz ±1 dB |
| THD+N | < 0.003 % @ 1 kHz |
| SNR | 112 dB (A-wt), 110 dB (un-wt) |
| Noise floor | < –93 dB |
| Display | 1.77-inch IPS color screen |
| Indicators | signal present, output mute, clip |
| Dimensions (W×H×D) | 482 × 44.5 × 265 mm |
| Weight | 3.5 kg |
| Core Advantage | Dual-Ecosystem-Driven Supply Chain Matrix |
| Strategic Ecosystem I | Core Partner in Global Smart Audio Systems |
| Strategic Ecosystem II | Strategic Manufacturer in Smart Interactive Display |
| Lightning Cloud Value | Integrated Solution Delivery Capability |
| Price | US$540.00 1 set(MOQ) |
| Supplier | Shandong Lightning Cloud Technology Engineering Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|---|
| Power | AC 220 V - 50 Hz |
| Audio connector | XLR |
| Input impedance | 10 kΩ |
| Output impedance | 100 Ω |
Additional data
| Technical Specifications (EN) | |
|---|---|
| 1 | DSP chip: 32-bit fixed/floating-point |
| 2 | Audio latency: < 2 ms |
| 3 | D/A conversion: 24-bit |
| 4 | Sampling rate: 96 kHz |
| 5 | Inputs: 2 / 3 / 4-channel options |
| 6 | Audio connector: XLR |
| 7 | Input impedance: 10 kΩ |
| 8 | Max input level: +14 dBu |
| 9 | Input delay: 0 – 500 ms per channel |
| 10 | Functions per channel: noise gate, compressor, HP/LP filters, 7-band PEQ |
| 11 | Signal generator: sine, pink, white noise |
| 12 | Outputs: 4 / 6 / 8-channel options |
| 13 | Output impedance: 100 Ω |
| 14 | Max output level: +14 dBu |
| 15 | Output delay: 0 – 500 ms per channel |
| 16 | Frequency response: 20 Hz – 20 kHz ±1 dB |
| 17 | THD+N: < 0.003 % @ 1 kHz |
| 18 | SNR: 112 dB (A-wt), 110 dB (un-wt) |
| 19 | Noise floor: < –93 dB |
| 20 | Channel crosstalk: < –100 dB @ 1 kHz |
| 21 | PC interfaces: RJ-45, USB, RS-485 |
| 22 | Display: 1.77-inch IPS color screen |
| 23 | Indicators: signal present, output mute, clip |
| 24 | Power: AC 220 V – 50 Hz |
| 25 | Dimensions (W×H×D): 482 × 44.5 × 265 mm |
| 26 | Weight: 3.5 kg |
| 27 | Operating temperature: –10 °C to +60 °C |
Product description
The supplier lists this product. Its stated application is Commercial, Home. The listed model is MA-306. The specifications below reflect the information publicly displayed on the listing. Noise: ≥105dB. Model NO.: MA-306. Speaker Material: Metal. Power: AC 220 V - 50 Hz. Audio connector: XLR. Input impedance: 10 kΩ. Output impedance: 100 Ω. Frequency response: 20 Hz – 20 kHz ±1 dB. Noise floor: < –93 dB.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Network Remote Control 3X6 Channel Professional 1u Rackmount Digital?
The listed minimum order quantity is 1 set. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Network Remote Control 3X6 Channel Professional 1u Rackmount Digital cost?
The published price is US$540.00 per set. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
MA-306 · US$540.00 · MOQ 1 set
