New Design 8inch 6000watt Ultra Thin Midbass Speaker.
- Impedance
- 8 Ohm
- Sensitivity
- 95.9 dB
- Style
- Big
- Usage
- Expand Volume
- Cone
- Paper
- WORD nChannels
- 2.1Channel
Specifications
| Product name | New Design 8inch 6000watt Ultra Thin Midbass Speaker. |
|---|---|
| Category | Other Speakers & Sound Systems |
| Customization | Available |
| Cone | Paper |
| Impedance | 8 Ohm |
| Model NO. | 8NDF65K1 |
| Usage | Expand Volume |
| WORD nChannels | 2.1Channel |
| AES Power Rating | 300 W |
| Program Power | 600 W |
| Frequency Range | 76-3500 Hz |
| Voice Coil | 2.5 Inch Alr |
| Sensitivity | 95.9 dB |
| Magnet | Neodymium |
| Chassis | Aluminum |
| Category | Speaker |
| Transmission Mode | Air-conduction |
| Transducer Principle | Permanent Magnetic Speaker |
| Radiation Mode | Direct Radiation Type |
| Certification | CCC, CE |
| Style | Big |
| Brand | Ci |
| Transport Package | Carton |
| Specification | 220x220x115 mm |
| Origin | China |
| HS Code | 8518290000 |
| Production Capacity | 50000 |
| Price | US$69.00-78.00 10 Pieces(MOQ) |
| Supplier | GUANGDONG HIWELL AUDIO CO., LTD |
| Data retrieved | 2026-10-23 |
Available options
| AES Power Rating | 300 W |
|---|---|
| Program Power | 600 W |
| Impedance | 8 Ohm |
Additional data
| Nominal diameter | mm (in.) | 203-213(8) |
|---|---|---|
| Nominal impedance | Ω | 8 |
| Minimum impedance | Ω | 7.2 |
| Program power (1) | W | 600 |
| AES Power rating(2) | W | 300 |
| Sensitivity (3) | dB | 95.9 |
| Frequency range | Hz | 76 ~ 3500 |
| Voice coil diameter | mm (in.) | 65(2.5) |
| Chassis material | Aluminum | |
| Magnet material | Neodymium | |
| Magnet dimensions (ODxIDxh) | mm | 64 x 15 x 10 |
| Coil material | CCAW | |
| Former material | Glass Fiber | |
| Xmax(4) | mm | 5 |
| Xmech(5) | mm | 9 |
| Gap height | mm | 8 |
| Voice coil Wingding height | mm | 14 |
| DC resistance | Re | Ohm | 5 |
|---|---|---|---|
| Resonance frequency | Fs | Hz | 76.7 |
| Moving mass | Mms | g | 28 |
| Compliance | Cms | mm/N | 0.15 |
| Force factor | BL | N/A | 16.1 |
| Mechanical Q-factor | Qms | 6.7 | |
| Electrical Q-factor | Qes | 0.31 | |
| Total Q-factor | Qts | 0.29 | |
| Equivalent air volume | Vas | I | 13 |
| Voice coil Inductance | Le | mH | 0.21 |
| Diaphragm area | Sd | cm² | 243 |
| Reference efficiency | Eta 0 | % | 2.2 |
| Net weight | Kg | 2.1 |
|---|---|---|
| Multipack size (1) (W x D x H) | mm | 220x220x115 |
| Multipack weight | Kg | 2.7 |
Product description
The supplier lists this product. Its stated application is Expand Volume. The listed model is 8NDF65K1. The specifications below reflect the information publicly displayed on the listing. Impedance: 8 Ohm. Model NO.: 8NDF65K1. AES Power Rating: 300 W. Program Power: 600 W. Frequency Range: 76-3500 Hz. Sensitivity: 95.9 dB.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for New Design 8inch 6000watt Ultra Thin Midbass Speaker.?
The listed minimum order quantity is 10 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does New Design 8inch 6000watt Ultra Thin Midbass Speaker. cost?
The published price is US$69.00 – 78.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
8NDF65K1 · US$69.00 – 78.00 · MOQ 10 Pieces
