PA Audio Line Array Speaker 15”neodymium Midrange, Powered Speaker Professional Loudspeaker.
PA, Stage & Line-Array Speakers

PA Audio Line Array Speaker 15”neodymium Midrange, Powered Speaker Professional Loudspeaker.

Model: 15NDF75U1 Customization available Speakers & Audio Systems
US$25.00 – 62.00
MOQ 1 Piece
Impedance
8 Ohm
Sensitivity
98 dB
Application
Stage
Activity
Passive
Operation Mode
No
Certification
CE, RoHS, FCC
Send Inquiry Full specifications

Specifications

Product namePA Audio Line Array Speaker 15”neodymium Midrange, Powered Speaker Professional Loudspeaker.
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
ActivityPassive
Model NO.15NDF75U1
Operation ModeNo
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating500 W
Program Power1000 W
Frequency Range45-3000Hz
Voice Coil3''vc Copper in/out
Sensitivity98 dB
Impedance8 Ohm
MagnetNeodymium
ChassisAluminum
Transport PackageCarton
Specification410 x 410 x 202 mm
OriginChina
HS Code8518290000
Production Capacity50000
PriceUS$25.00-62.00 1 Piece(MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

AES Power Rating500 W
Program Power1000 W
Impedance8 Ohm

Additional data

Nominal diametermm (in.)389(15)
Nominal impedanceΩ8
Minimum impedanceΩ6.9
Program power (1)W1000
AES Power rating(2)W500
Sensitivity (3)dB98
Frequency rangeHz45 ~ 3000
Voice coil diametermm (in.)75(3)
Chassis materialAluminum
Magnet materialNeodymium
Magnet dimensions (ODxIDxh)mm74 x 15 x 10
Coil materialSV
Former materialGlass Fiber
Xmax(4)mm7.5
Xmech(5)mm13
Gap heightmm10
Voice coil Wingding heightmm20
DC resistanceReOhm5.5
Resonance frequencyFsHz45
Moving massMmsg85
ComplianceCmsmm/N0.14
Force factorBLN/A18.9
Mechanical Q-factorQms9.4
Electrical Q-factorQes0.38
Total Q-factorQts0.36
Equivalent air volumeVasI147
Voice coil InductanceLemH0.7
Diaphragm areaSdcm²880
Reference efficiencyEta 0%2.7
Net weightKg5.1
Multipack size (1) (W x D x H)mm410 x 410 x 202
Multipack weightKg6

Product description

The supplier lists this product. Its stated application is Stage. The listed model is 15NDF75U1. The specifications below reflect the information publicly displayed on the listing. Noise: 0. Model NO.: 15NDF75U1. AES Power Rating: 500 W. Program Power: 1000 W. Frequency Range: 45-3000Hz. Sensitivity: 98 dB. Impedance: 8 Ohm.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for PA Audio Line Array Speaker 15”neodymium Midrange, Powered Speaker?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does PA Audio Line Array Speaker 15”neodymium Midrange, Powered Speaker cost?

The published price is US$25.00 – 62.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
