Passive Three-Way Line Array Speaker for Large-Size Performance
PA, Stage & Line-Array Speakers

Passive Three-Way Line Array Speaker for Large-Size Performance

Model: LA312 Customization available Speakers & Audio Systems
US$800.00 – 1,280.00
MOQ 4 Pieces
Application
Commercial
Noise
<95dB
Activity
Passive
Speaker Material
Wood
Certification
CE, RoHS
THD
<0.03%
Send Inquiry Full specifications

Specifications

Product namePassive Three-Way Line Array Speaker for Large-Size Performance
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Noise<95dB
ActivityPassive
Model NO.LA312
Speaker MaterialWood
ApplicationCommercial
CertificationCE, RoHS
THD<0.03%
System TypeDual 12inch, Three-Way Line Array Speaker
Frequency Range40Hz -- 20kHz
Maximum Peak Output139db
Transport PackageCarton or Flightcase
SpecificationCE, RoHS
OriginGuangzhouchina
HS Code851822000
Production Capacity5000 Units Per Month
LF800W Continuou. 1600W Peak.
MF300W Continuou. 600W Peak.
HF180W Continuou. 360W Peak.
PriceUS$800.00-1,280.00 4 Pieces(MOQ)
SupplierTDS ACOUSTIC CO., LIMITED
Data retrieved2026-10-23

Available options

Speaker MaterialWood

Additional data

TECHNICAL SPECIFICATION
Frequency Range (-10dB)40Hz -- 20KHz
Frequency Response(±3dB)60Hz -- 18KHz
Horizontal Coverage Angle (-6dB)90°
Vertical Coverage Angle(-6dB)10°
System Input Power RatingLF: 800W Continuou. 1600W Peak.
MF: 300W Continuou. 600W Peak.
HF: 180W Continuou. 360W Peak.
Maxium Peak Output139 dB
Recommended AmplificationLF 1200W into 8 ohm.
MF 800W into 8 ohm.
HF 600W into 8 ohm.
PHYSICAL DATA
Dimensions ( W x H x D )1120 x 390 x 500 mm
Net Weight56 kg
Connectors2 x NL8MP Neutrik Speakon Connectors
Cabinet Material18mm Birch Plywood

Product description

The supplier lists this product. Its stated application is Commercial. The listed model is LA312. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: LA312. Speaker Material: Wood. Frequency Range: 40Hz -- 20kHz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Passive Three-Way Line Array Speaker for Large-Size Performance?

The listed minimum order quantity is 4 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Passive Three-Way Line Array Speaker for Large-Size Performance cost?

The published price is US$800.00 – 1,280.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
