Pilot Headphone Aviation Headset for Ga
Call Center, Business & Aviation Headsets

Pilot Headphone Aviation Headset for Ga

Model: PH-100A Customization available Headphones & Earphones
US$75.0050–99 Pieces
US$70.00100+ Pieces
MOQ 50 Pieces
Communication
Wired
Impedance
150 ohms (300 ohms each; wired in parallel)
Frequency Response
100Hz to 8 kHz
Sensitivity
95+/-5 dB SPL
Jack Diameter
6.3mm
Jack Type
Plug-in
Send Inquiry Full specifications

Specifications

Product namePilot Headphone Aviation Headset for Ga
CategoryCall Center, Business & Aviation Headsets
CustomizationAvailable
Wire MaterialPU
ColorBlue, Red, Black
Model NO.PH-100A
TypeMoving-Iron Headphones
CommunicationWired
UsageAviation
FunctionNoise-Canceling
Jack Diameter6.3mm
Jack TypePlug-in
ItemHigh Quality Airlines Headphone Aviation Headset P
ConnectorsPj-055/Pj-068
Use forAviation, Pilot, Airline, etc
Function 1Microphone, Noise Canceling
Earphone PlugPj-055( .25"F6.3 Phone Plug)
Microphone PlugPj-068( .206"F5.2 Phone Plug)
Operating Temperature-20 to 70 °c
Weight530g
Warranty12 Months
Transport Package1PCS/White Box, Pack All in The Carton.
SpecificationCE
OriginChina
HS Code8517704000
Production Capacity10, 000PCS/Month
Product DescriptionsRAN-1000A PNR Aviation headset Noise canceling headset
Straight cord from headset to molded plug150CM
Noise Reduction Ratings (NRR)24dB
Frequency Response100Hz to 8 kHz
Sensitivity95+/-5 dB SPL
Impedance150 ohms (300 ohms each; wired in parallel)
Rate Input100mW
Max. Input250mW
Element TypeNoise-canceling electret
Operating Voltage (supplied by aircraft )8-32 Volts DC
Matching Impedance150-1000 ohms
CordageStraight cord from headset to molded
Weights530g
Headset size range Height10 to 14 cm
BoomSpring tension boom
HYT(Hytera)TC-268, TC-368, TC-268S, TC-368S, TC-370M, TC-380M, TC-3000, TC-3600, TC-3600M, PT-790, TC-780, TC-500, TC-600, TC-700, TC-610, TC-620, TC-2110, TC-1600, TC-510, CPS, CP-380, CP-330, CP-150, CP-350, CP-220, TC-500S, TC-585, TC-610S, TC-720S, TC-710, TC-510
PriceUS$75.00 50-99 Pieces US$70.00 100+ Pieces
SupplierRAYTALK COMMUNICATIONS LTD
Data retrieved2026-10-23

Available options

Wire MaterialPU
Color
BlueRedBlack
Jack Diameter6.3mm
ConnectorsPj-055/Pj-068
Impedance
150 ohms (300 ohms eachwired in parallel)
Matching Impedance150-1000 ohms

Additional data

Product Descriptions:
RAN-1000A PNR Aviation headset Noise canceling headset
AVIATION HEADSETS, INTERCOMS AND ACCESSORIES
Overview
PNR Aviation Headset
PlugsGA Use Dual Plug
Super Soft Double Foam Head Pad
New Comfort foam, undercut ear seals
Molded cord assembly made to exceptional pull and flex standards
Noise-canceling electret
Strong Steel Boom provides flexibility and steady microphone placement
Straight cord from headset to molded plug:150CM
Noise Reduction Ratings (NRR):24dB
Specifications
Headphone
Type:Dynamic (F50)
Frequency Response:100Hz to 8 kHz
Sensitivity:95+/-5 dB SPL
(1 kHz, 1 mW input per earcup side)
full volume on ear simulator
Impedance:150 ohms (300 ohms each; wired in parallel)
Rate Input:100mW
Max. Input:250mW
Microphone and Amplifier:
Element Type:Noise-canceling electret
Frequency Response:100Hz to 5 kHz
Operating Voltage (supplied by aircraft ):8-32 Volts DC
Matching Impedance:150-1000 ohms
Sensitivity:33+/4 dB
(ref: 0dB SPL=20.0uPa at 1 kHz with 10 Vdc 150 ohms AC load)
General
Operating Temperature:below 20 to 70 °C
Cordage:Straight cord from headset to molded
plug,150CM
Intercom Connections Plug:
Earphone Plug:PJ-055( .25"F6.3 phone plug)
Microphone Plug:PJ-068( .206"F5.2 phone plug)
Weights:530g
Headset size range Height:10 to 14 cm
Color:Green/Black/Pink/Red/Yellow/Blue/White/Gray
Boom:Spring tension boom

Product description

The supplier lists this product as Moving-Iron Headphones. Its stated application is Aviation. The listed model is PH-100A. Supplier-stated function: Noise-Canceling. The specifications below reflect the information publicly displayed on the listing. Wire Material: PU. Model NO.: PH-100A. Connectors: Pj-055/Pj-068. Noise Reduction Ratings (NRR): 24dB. Frequency Response: 100Hz to 8 kHz. Sensitivity: 95+/-5 dB SPL. Impedance: 150 ohms (300 ohms each; wired in parallel). Matching Impedance: 150-1000 ohms.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Pilot Headphone Aviation Headset for Ga?

The listed minimum order quantity is 50 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Pilot Headphone Aviation Headset for Ga cost?

The published price is US$70.00 – 75.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
