Portable Speaker Microphone for HYT Tc600/Tc700/Tc2100/Tc500
Microphones & Audio System Accessories

Portable Speaker Microphone for HYT Tc600/Tc700/Tc2100/Tc500

Model: RSM100/Hyt1 Customization available Cables, Adapters & Audio Electronics
US$7.00
MOQ 50 Pieces
Impedance
8 Ω ± 15%
Sensitivity
-40 ± 3dB
Material
Thermoplastic polyurethanes
Style
Handheld Microphone
Application
Voice
Color
Black
Send Inquiry Full specifications

Specifications

Product namePortable Speaker Microphone for HYT Tc600/Tc700/Tc2100/Tc500
CategoryMicrophones & Audio System Accessories
CustomizationAvailable
StyleHandheld Microphone
ApplicationVoice
Model NO.RSM100/Hyt1
Signal TransmissionWired
DirectivityOmni-direction
BrandRtc
ModelRsm-100
Radio BrandHYT
Radio ModelTc2100, Tc500, Tc600, Tc610, Tc620, Tc700, Tc6100
Transport PackagePolybag Pack for Each Item,Pack All in The Carton.
OriginChina
Production Capacity1000PCS/Week
DimensionØ 9.7 X 6.5mm
Sensitivity-40 ± 3dB
DirectionOmnidirectional
Output Impedance2.2K Ω
Current Consumption500A
Working Voltage1.5V
Audio Response50Hz 10kHz
Impedance8 Ω ± 15%
Output Sound Pressure Level80± 3dB
Power RatingNormal. 05W
Frequency Range280Hz-6kHz average
Cable DiameterØ 3.8mm
Cable Length45cm 1.5m
ColorBlack
MaterialThermoplastic polyurethanes
Optional connectorsFor Motorola/Kenwood/Icom/HYT/Vertex//Sepura/Tait, etc
DimensionsΦ 45mm
Rated Input Power500mW
Sound Pressure Leavel103 4dB @ 1KHz
PriceUS$7.00 50 Pieces(MOQ)
SupplierRAYTALK COMMUNICATIONS LTD
Data retrieved2026-10-23

Available options

Radio Model
Tc2100Tc500Tc600Tc610Tc620Tc700Tc6100
Output Impedance2.2K Ω
Working Voltage1.5V
Impedance8 Ω ± 15%
Power RatingNormal. 05W
Cable DiameterØ 3.8mm

Additional data

Microphone: Sensitivity: -36dB± 3dB @ 1000Hz(0dB=1V/Pa) Impedance: 2.2KΩ @ 1KHz Operating Voltage" 1.1-10VDCSpeaker: Dimensions: Φ 45mm Impedance: 8Ω ±15% @ 1000Hz Rated Input Power: 500mW Sound Pressure Leavel: 103 4dB @ 1KHz

Product description

The supplier lists this product. Its stated application is Voice. The listed model is RSM100/Hyt1. The specifications below reflect the information publicly displayed on the listing. Model NO.: RSM100/Hyt1. Model: Rsm-100. Radio Model: Tc2100, Tc500, Tc600, Tc610, Tc620, Tc700, Tc6100. Sensitivity: -40 ± 3dB. Output Impedance: 2.2K Ω. Impedance: 8 Ω ± 15%. Power Rating: Normal. 05W. Frequency Range: 280Hz-6kHz average. Material: Thermoplastic polyurethanes. Optional connectors: For Motorola/Kenwood/Icom/HYT/Vertex//Sepura/Tait, etc.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Portable Speaker Microphone for HYT Tc600/Tc700/Tc2100/Tc500?

The listed minimum order quantity is 50 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Portable Speaker Microphone for HYT Tc600/Tc700/Tc2100/Tc500 cost?

The published price is US$7.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
