PRO Audio Fp Series 4 Channesl Sp10000q High Performance Power Amplifier 4X1300W Class-Td Amplifier
- Type
- Power Amplifier
- Peak Power Output(All CH Driven)
- 10000W
- Peak Output Voltage (Per CH)
- 150V
- Max Output Current (Per CH)
- 54A Peak
- 16 Ohm Per CH(All CH Driven)
- 660W
- 8 Ohm Per CH(All CH Driven)
- 1300W
Specifications
| Product name | PRO Audio Fp Series 4 Channesl Sp10000q High Performance Power Amplifier 4X1300W Class-Td Amplifier |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Model NO. | SP10000Q |
| Peak Power Output(All CH Driven) | 10000W |
| Peak Output Voltage (Per CH) | 150V |
| Max Output Current (Per CH) | 54A Peak |
| 16 Ohm Per CH(All CH Driven) | 660W |
| 8 Ohm Per CH(All CH Driven) | 1300W |
| 4 Ohm Per CH(All CH Driven) | 2100W |
| 2 Ohm Per CH(All CH Driven) | 2500W |
| 16 Ohm Per CH(Bridge) | 2600W |
| 8 Ohm Per CH (Bridge) | 4200W |
| 4 Ohm Per CH(Bridge) | 5000W |
| Transport Package | Plastic Bag + Thick Foam + Strong Brown Packing Ca |
| Specification | 580X560X200mm |
| Origin | China |
| HS Code | 8518400090 |
| Production Capacity | 2000PCS/Month |
| Customization | Available |
| Type | Power Amplifier |
| Channels | 4 |
| Model Number | SP10000Q |
| A+B channel | A is signal input,speaker output connecting A+ and B-,C+D channel C |
| Trade Term | EXW or FOB Guangzhou |
| Payment | Paypal/T/T, 30% as deposit before production, and the balance paid before shipment. (L/C acceptable) |
| Delivery | About 4 weeks after getting deposit. |
| Price | US$400.00-700.00 5 Pieces (MOQ) |
| Supplier | Guangzhou strong sound electronic equipment Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Peak Power Output(All CH Driven) | 10000W |
|---|---|
| Peak Output Voltage (Per CH) | 150V |
| Model Number | SP10000Q |
Additional data
| Channels | 4 |
|---|---|
| Peak Power output(all CH driven) | 10000W |
| Peak Output Voltage (per CH) | 150V |
| Max output current (per CH) | 54A peak |
| Max Output Power | |
| 16 Ohm per CH(all CH driven) | 660W |
| 8 Ohm per CH(all CH driven) | 1300W |
| 4 Ohm per CH(all CH driven) | 2100W |
| 2 Ohm per CH(all CH driven) | 2500W |
| 16 Ohm per CH(Bridge) | 2600W |
| 8 Ohm per CH (Bridge) | 4200W |
| 4 Ohm per CH(Bridge) | 5000W |
| 2 Ohm per CH(Bridge) | |
| Gain | 35dB and VPL:150V |
| 1W,20Hz-20KHz THD | <0.1% |
| 1KHz and 1dB below clipping THD | <0.05% |
| SNR | >112dBA |
| 1kHz(CROSSTALK) | >70dB |
| Frequency Response | 6.8Hz-34kHz |
| Input Impedance | 20k Ohm |
| CMR | 54dB |
| Output Impedance @100Hz | 32m Ohm |
| Peak Voltage Limiter(VPL),MAX OUTPUT | |
| VPL,per channel optional(V) | 155.121.101.83. |
| 70.56.47.38V | |
| VPL,bridge optional(V) | 300.242.202.166. |
| 140.112.94.76V | |
| Peak Voltage Limiter mode(Per CH) | Hard / Soft |
| Default Gain | 35dB |
| AMP GAIN(all CH) | 23,26,29,32,35,38,41,44 dB |
| Level Control(all CH) | front panel potential device;,from -∞ to 0dB |
| Input Jack(all CH) | 3 pins XLR female |
| Output Jack(all CH) | Speakon |
| Output bridge mode (each two CH) | A+B channel: A is signal input,speaker output connecting A+ and B-,C+D channel C |
| is signal input? speaker output connecting C+ and D- |
Product description
The supplier lists this product as Power Amplifier. The listed model is SP10000Q. The specifications below reflect the information publicly displayed on the listing. Model NO.: SP10000Q. Peak Power Output(All CH Driven): 10000W. Model Number: SP10000Q.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for PRO Audio Fp Series 4 Channesl Sp10000q High Performance Power?
The listed minimum order quantity is 5 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does PRO Audio Fp Series 4 Channesl Sp10000q High Performance Power cost?
The published price is US$400.00 – 700.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
