Professional Active Audio 12 Inch Subwoofer 2 Way Line Array Powered Speakers
- Type
- 3 Way Active Line Array
- Application
- Commercial, Home
- Color
- Black
- Noise
- <95dB
- Hi-Fi
- Hi-Fi
- Activity
- Active
Specifications
| Product name | Professional Active Audio 12 Inch Subwoofer 2 Way Line Array Powered Speakers |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Hi-Fi |
| Model NO. | MX-A3A&A518 |
| Activity | Active |
| Operation Mode | Wire / Remote Control |
| Speaker System | 5.1 Channel |
| Speaker Material | Metal |
| Application | Commercial, Home |
| Certification | CE, RoHS |
| Monitor | No |
| THD | <0.05% |
| Frequency Range (Hz) | 58Hz-20kHz |
| Type | 3 Way Active Line Array |
| Active Line Array | Class D Amplifier Module |
| on-Board DSP | Enable for Remote Control |
| Warranty | 2 Years |
| Color | Black |
| Transport Package | Carton or Flight Case Packing |
| Specification | 582× 414× 343mm |
| Origin | Guangdong, China |
| Production Capacity | 50000 |
| Top | A3,active 2-way single 12" line-array, |
| HF | 2x2.4"Neo,8ohm 160W,Original Celestion Driver(CDX4-2420)from UK ,neodynium |
| LF | 12"Neo,500W ,Original Paudio Driver ,neodynium |
| With 2 channel amplifier,Class-D,output power | 600W+1200W,with built-in DSP made in Germany |
| MF | 500W/2000W/ HF:160W/320W |
| Sub | A3-sub,active single 18" line-array, |
| Configuration | 18",800W |
| With Class-D,output power | 1200W,with built-in DSP made in Germany |
| Price | US$500.00-800.00 1 Piece(MOQ) |
| Supplier | Guangzhou MINGXUAN Stage Light Equipment CO.,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|---|
| Color | Black |
| With Class-D,output power |
Additional data
| Configuration | 1*12inch MF+2*2.4inch HF |
|---|---|
| Power(AES/Peak) | MF:500W/2000W/ HF:160W/320W |
| Impedance | 4Ohm/ 4Ohm |
| Sencitivity (1 W/m) | MF:106dB/HF:116dB |
| Rated Maximum SPL | MF:130dB/HF:136dB ( peak@1m) |
| Dispertion angle(V x H) | H120°x V20° |
| Input Impedance | 20 KΩ |
| Input Sensitivity | 0.775V |
| Amplifier Output Power | 600W+1200W/4ohm |
| Power Connector | Power Con |
| Operating Voltage | 90~ 120V/190~ 240V |
| Damping Factor | ≥400 |
| Weight | 24Kg |
| Shipping Size | 582x414x 343mm |
| Configuration | 1*18inch |
|---|---|
| Power(AES/Peak) | 800W |
| Impedance | 8Ω |
| Sencitivity (1 W/m) | 102dB |
| Rated Maximum SPL | 131dB ( peak@1m) |
| Franquency Range | 35Hz- 220KHz (+3dB) |
| Input Impendance | 20 KΩ |
| Input Sensitivity | 0.775V |
| Amplifier Output Power | 1200W/8ohm |
| Power Connector | Power Con |
| Operating Voltage | 90~ 120V/190~240V |
| Damping Factor | ≥400 |
| Weight | 49Kg |
| Shipping Size | 582*838x 800mm |
Product description
The supplier lists this product as 3 Way Active Line Array. Its stated application is Commercial, Home. The listed model is MX-A3A&A518. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: MX-A3A&A518. Speaker Material: Metal. Frequency Range (Hz): 58Hz-20kHz. With 2 channel amplifier,Class-D,output power: 600W+1200W,with built-in DSP made in Germany. With Class-D,output power: 1200W,with built-in DSP made in Germany.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Professional Active Audio 12 Inch Subwoofer 2 Way Line Array Powered?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Professional Active Audio 12 Inch Subwoofer 2 Way Line Array Powered cost?
The published price is US$500.00 – 800.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
