Professional Audio 220mm Magnet 4″ Vc
- AES Power Handing
- 300W
- Sensitivity 1W/1m
- 93dB
- Frequency Range
- 54-3.5kHz
- Nominal Diameter
- 460mm/18inch
- Nominal Impedance
- 8 Ohm
Specifications
| Product name | Professional Audio 220mm Magnet 4″ Vc |
|---|---|
| Category | Other Audio Cables & Electronics |
| Model NO. | EL18-600 |
| AES Power Handing | 300W |
| Sensitivity 1W/1m | 93dB |
| Frequency Range | 54-3.5kHz |
| Transport Package | Carton |
| Specification | 460*185 |
| Origin | China |
| HS Code | 85182900 |
| Production Capacity | 100000 PCS/Year |
| Customization | Available |
| Nominal Diameter | 460mm/18inch |
| Nominal Impedance | 8 Ohm |
| Price | US$67.90 1-99 Pieces US$62.90 100-999 Pieces US$57.90 1,000+ Pieces |
| Supplier | Meirui (Guangdong) Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| AES Power Handing | 300W |
|---|---|
| Nominal Diameter | 460mm/18inch |
| Nominal Impedance | 8 Ohm |
Additional data
| General Specifications | ||
|---|---|---|
| Nominal Diameter | 460mm/18inch | |
| Nominal Impedance | 8Ω | |
| AES Power Handing | 300W (AES) | |
| Maximum Power | 500W | |
| Sensitivity 1W/1M | 93dB | |
| Frequency Range | 54-3.5kHz | |
| Voice Coil Diameter | 99.5mm/4 inch | |
| Windinig Material | Copper | |
| Former Material | Aluminum | |
| Winding Depth | 21.5mm | |
| surround material | Polycotton | |
| surround Design | M-roll | |
| Magnet | Φ220 | Ferrite Ring |
| Thiele & Small Parameters | ||
| Resonance Frequency | Fs | 54Hz |
| DC Resistance | Re | 5.5Ω |
| Mechanical Factor | Qms | 8.15 |
| Electrical Factor | Qes | 1.42 |
| Total Factor | Qts | 1.21 |
| BL Factor | BL | 18T.m |
| Effective Moving Mass | Mms | 247g |
| Compliance | Cms | 35μ M/N |
| Equivalent Cas Air Load | Vas | 74L |
| Effettive Piston Area | Sd | 1225cm² |
| η(Eta Zero) | η0 | 0.8% |
| Mountiong & Shipping Information | ||
| Overall Diameter | 460mm | |
| Bolt circle diameter | 440mm | |
| Baffle Cutout Diameter | 422mm | |
| Depth | 185mm | |
| Net Weight | 9.7kg | |
| Shipping Weight | 10.7kg | |
| Shipping Box(Single) | 48*48*25cm |
Product description
The supplier lists this product. The listed model is EL18-600. The specifications below reflect the information publicly displayed on the listing. Model NO.: EL18-600. AES Power Handing: 300W. Sensitivity 1W/1m: 93dB. Frequency Range: 54-3.5kHz. Nominal Impedance: 8 Ohm.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Professional Audio 220mm Magnet 4″ Vc?
The listed minimum order quantity is 1 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Professional Audio 220mm Magnet 4″ Vc cost?
The published price is US$57.90 – 67.90 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
EL18-600 · US$57.90 – 67.90 · MOQ 1 Pieces
