Professional Audio More Powered 8 Inch Dual Coils 800watt Loudspeaker.
PA, Stage & Line-Array Speakers

Professional Audio More Powered 8 Inch Dual Coils 800watt Loudspeaker.

Model: 8NDF75C1 Customization available Speakers & Audio Systems
US$69.00 – 78.00
MOQ 10 Pieces
Impedance
8 Ohm
Sensitivity
97.3 dB
Application
Stage
Operation Mode
No
Certification
CE, RoHS, FCC
AES Power Rating
400 W
Send Inquiry Full specifications

Specifications

Product nameProfessional Audio More Powered 8 Inch Dual Coils 800watt Loudspeaker.
CategoryPA, Stage & Line-Array Speakers
Model NO.8NDF75C1
Operation ModeNo
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating400 W
Program Power800 W
Frequency Range64-3500 Hz
Voice Coil3 Inch Alr
Sensitivity97.3 dB
Impedance8 Ohm
MagnetNeodymium
ChassisAluminum
Transport PackageCarton
Specification220x220x158 mm
OriginChina
HS Code8518290000
Production Capacity50000
CustomizationAvailable
ActivityPassive
PriceUS$69.00-78.00 10 Pieces (MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

AES Power Rating400 W
Program Power800 W
Impedance8 Ohm

Additional data

Nominal diametermm (in.)213(8)
Nominal impedanceΩ8
Minimum impedanceΩ7.2
Program power (1)W800
AES Power rating(2)W400
Sensitivity (3)dB97.3
Frequency rangeHz64 ~ 3500
Voice coil diametermm (in.)75(3)
Chassis materialAluminum
Magnet materialNeodymium
Magnet dimensions (ODxIDxh)mm74 x 15 x 10
Coil materialALR
Former materialGlass Fiber
Xmax(4)mm5.5
Xmech(5)mm11
Gap heightmm10 x 2
Voice coil Wingding heightmm36
DC resistanceReOhm5.8
Resonance frequencyFsHz63.7
Moving massMmsg31
ComplianceCmsmm/N0.2
Force factorBLN/A21.9
Mechanical Q-factorQms5
Electrical Q-factorQes0.18
Total Q-factorQts0.17
Equivalent air volumeVasI16
Voice coil InductanceLemH2.2
Diaphragm areaSdcm²240
Reference efficiencyEta 0%2.6
Net weightKg2.3
Multipack size (1) (W x D x H)mm220x220x158
Multipack weightKg2.7

Product description

The supplier lists this product. Its stated application is Stage. The listed model is 8NDF75C1. The specifications below reflect the information publicly displayed on the listing. Model NO.: 8NDF75C1. AES Power Rating: 400 W. Program Power: 800 W. Frequency Range: 64-3500 Hz. Sensitivity: 97.3 dB. Impedance: 8 Ohm. Noise: 0.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Professional Audio More Powered 8 Inch Dual Coils 800watt Loudspeaker.?

The listed minimum order quantity is 10 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Professional Audio More Powered 8 Inch Dual Coils 800watt Loudspeaker. cost?

The published price is US$69.00 – 78.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
