Professional Audio Studio 12 Inch Speaker for Indoor Installation
PA, Stage & Line-Array Speakers

Professional Audio Studio 12 Inch Speaker for Indoor Installation

Model: U112VH Customization available Speakers & Audio Systems
US$1.00 – 3,000.00
MOQ 1 Piece
Rated Power
300W RMS, 1200W Peak
Impedance
8 Ohms Nominal
Sensitivity
97dB 1 Watt/1 Meter
Woofer
1X12"(300mm)/3" Voice Coil Woofer
Driver
1X1"(25mm)/1.7" Voice Coil Tweeter
Maximum Spl
122dB Continuous, 128dB Peak
Send Inquiry Full specifications

Specifications

Product nameProfessional Audio Studio 12 Inch Speaker for Indoor Installation
CategoryPA, Stage & Line-Array Speakers
Model NO.U112VH
Woofer1X12"(300mm)/3" Voice Coil Woofer
Driver1X1"(25mm)/1.7" Voice Coil Tweeter
Rated Power300W RMS, 1200W Peak
Sensitivity97dB 1 Watt/1 Meter
Impedance8 Ohms Nominal
Maximum Spl122dB Continuous, 128dB Peak
Dispersion(-6dB)90°X40°
Crossover Frequencies2kHz Passive
CertificateCe, RoHS, CCC
Transport PackageCarton Box
Specification374x353x605mm
OriginDongguan, China
HS Code8518220000
Production Capacity5000PCS/Month
CustomizationAvailable
Speaker MaterialPlywood
Frequency Response(-3dB)50Hz-18kHz
Applications1.Multi-purpose Halls
Factory IntroductionFDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors.
Webfdbaudiochina.en.made-in-china.com
PriceUS$1.00-3,000.00 1 Piece (MOQ)
SupplierDONGGUAN FDB AUDIO MANUFACTURE CO .,LTD
Data retrieved2026-10-23

Available options

Rated Power
300W RMS1200W Peak
Speaker MaterialPlywood
Impedance8 Ohms Nominal

Additional data

FREQUENCY RESPONSE(-3dB)50 Hz-18kHz
DRIVERS1×12"(200mm)/3"voice coil LF
1×1.4"(36mm)/1.7"voice coil HF
RATED POWER450W RMS,1800W peak
SENSITIVITY97dB 1watt/1 meter
MAXIMUM SPL124dB continuous,130dB peak
IMPEDANCE8 ohms nominal
DISPERSION(-6dB)90°×40°
CROSSOVER FREQUENCIES2kHz passive
INPUT CONNECTORS2×Speakon NL4
PACKING SIZE490mm×470mm×730mm
NET WEIGHT25kg/pc
GROSS WEIGHT29 kg/pc

Product description

The supplier lists this product. The listed model is U112VH. The specifications below reflect the information publicly displayed on the listing. Model NO.: U112VH. Driver: 1X1"(25mm)/1.7" Voice Coil Tweeter. Rated Power: 300W RMS, 1200W Peak. Sensitivity: 97dB 1 Watt/1 Meter. Impedance: 8 Ohms Nominal. Speaker Material: Plywood. Frequency Response(-3dB): 50Hz-18kHz.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Professional Audio Studio 12 Inch Speaker for Indoor Installation?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Professional Audio Studio 12 Inch Speaker for Indoor Installation cost?

The published price is US$1.00 – 3,000.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
