Professional Digital Processor PA2 2 Input 6 Output Speaker Line Array Sound Equipment Audio Processor
- Frequency Response
- 20 Hz – 20 kHz, +0 /- 0.5 dB
- Type
- Audio Processor
- Usage
- Hi-Fi, AV, KTV System, Stage, Professional Performance
- Used For
- Professional
- Tube Type
- Transistor Amplifier
- Function
- Post Amplifier, Amplifier Combined, Pre-amplifier
Specifications
| Product name | Professional Digital Processor PA2 2 Input 6 Output Speaker Line Array Sound Equipment Audio Processor |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Type | Audio Processor |
| Usage | Hi-Fi, AV, KTV System, Stage, Professional Performance |
| Model NO. | PA2 |
| Used For | Professional |
| Tube Type | Transistor Amplifier |
| Function | Post Amplifier, Amplifier Combined, Pre-amplifier |
| Sound Channel | 2 |
| Output Number | 6 |
| Voltage | 100-120 VAC 50/60 Hz or 220-240 VAC 50/60 Hz |
| Element Number | Monoamplifier |
| Conductive Mode | D |
| Processor Name | PA2 Digital Processor |
| Number of Inputs | 2 Line Inputs, 1 Rta Mic Input |
| Number of Outputs | 6 Line Outputs |
| Frequency Response | 20 Hz – 20 kHz, +0 /- 0.5 dB |
| Thd+Noise | 0.003% Typical at +4 Dbu, 1 kHz, 0 dB Input Gain |
| Latency | Input to Output: 1.847 Ms |
| Operating Voltage | 100-120 VAC 50/60 Hz or 220-240 VAC 50/60 Hz |
| Power Consumption | 22 Watts |
| Dimensions | 4.4cm (H) X 14.6cm (D) X 48.26cm (W) |
| Unit Weight | 2.4 Kg |
| Warranty | 2 Years |
| Safety/Compliance | CE, FCC, RoHS |
| Service | OEM ODM Support ;After-Sale Service |
| Transport Package | Strong Packing |
| Specification | 3.1 kg |
| Origin | Guangdong Province, China |
| HS Code | 8542310000 |
| Production Capacity | 1000 Units/ Month |
| Package Size | 50.00cm * 45.00cm * 10.00cm |
| Package Gross Weight | 6.000kg |
| Input to output | 1.847 ms |
| PA2 processor Features | Stereo feedback suppressor 2×12 group fast tracking notch filter. |
| Price | US$200.00-250.00 1 Piece(MOQ) |
| Supplier | Guangzhou Xinbaosheng Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | 100-120 VAC 50/60 Hz or 220-240 VAC 50/60 Hz |
|---|---|
| Operating Voltage | 100-120 VAC 50/60 Hz or 220-240 VAC 50/60 Hz |
| Power Consumption | 22 Watts |
Additional data
| ANALOG INPUTS | |
|---|---|
| Number of Inputs | 2 line inputs, 1 RTA mic input |
| Connectors | 2 female XLR line inputs, 1 female XLR RTA mic input |
| Type | Electronically balanced/RF filtered |
| Impedance | > 50 kΩ |
| Max Input Level (line inputs) | > +20 dBu |
| CMRR | > 45 dB |
| RTA Mic Preamp Phantom Power | +15 VDC |
| ANALOG OUTPUTS | |
| Number of Outputs | 6 line outputs |
| Connectors | Male XLR |
| Type | Electronically balanced, RF filtered |
| Impedance | 120 Ω |
| Max Output Level | +20 dBu |
| Alignment Delay | Up to 10ms per output channel pair |
| A/D PERFORMANCE | |
| A/D Converter | 24-bit with Type IV™ Conversion System |
| A/D Dynamic Range | 112 dB A-weighted, 110 dB unweighted |
| Type IV Dynamic Range | 123 dB with transient material, A-weighted, 22kHz BW; |
| 121 dB with transient material, unweighted, 22kHz BW; | |
| 115 dB typical with program material, A-weighted, 22kHz BW | |
| D/A PERFORMANCE | |
| D/A Converter | 24-bit |
| D/A Dynamic Range | 112 dB A-weighted, 110 dB unweighted |
| SYSTEM PERFORMANCE | |
| Internal Processing Wordlength | 32-bit floating point |
| Sample Rate | 48 kHz |
| Dynamic Range | 110 dB A-weighted |
| 107 dB unweighted | |
| THD+Noise | 0.003% typical at +4 dBu, 1 kHz, 0 dB input gain |
| Frequency Response | 20 Hz - 20 kHz, +0 /- 0.5 dB |
| Interchannel Crosstalk | < -110 dB, -120 dB typical (input-to-output: < -100 dB) |
| Latency | Input to output: 1.847 ms |
| POWER SUPPLY | |
| Operating Voltage | 100-120 VAC 50/60 Hz or 220-240 VAC 50/60 Hz |
| Power Consumption | 22 Watts |
Product description
The supplier lists this product as Audio Processor. Its stated application is Hi-Fi, AV, KTV System, Stage, Professional Performance. The listed model is PA2. Supplier-stated function: Post Amplifier, Amplifier Combined, Pre-amplifier. The specifications below reflect the information publicly displayed on the listing. Model NO.: PA2. Frequency Response: 20 Hz – 20 kHz, +0 /- 0.5 dB. Thd+Noise: 0.003% Typical at +4 Dbu, 1 kHz, 0 dB Input Gain. Power Consumption: 22 Watts.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Professional Digital Processor PA2 2 Input 6 Output Speaker Line?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Professional Digital Processor PA2 2 Input 6 Output Speaker Line cost?
The published price is US$200.00 – 250.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
PA2 · US$200.00 – 250.00 · MOQ 1 Piece
