Professional Low-Noise Audio Multi-Pair Cable Instrument Snake Cable
- Application
- Construction, Overhead, Industrial, Power Station, Telecommunication
- Voltage
- Low and Medium Voltage Cable
- Current
- DC & AC
- Insulation Material
- PE
- Sheath Material
- PVC/XLPE/PE
- Material Shape
- Round Wire
Specifications
| Product name | Professional Low-Noise Audio Multi-Pair Cable Instrument Snake Cable |
|---|---|
| Category | XLR & Professional Audio Cables |
| Customization | Available |
| Application | Construction, Overhead, Industrial, Power Station, Telecommunication |
| Voltage | Low and Medium Voltage Cable |
| Model NO. | Instrument Cable |
| Current | DC & AC |
| Insulation Material | PE |
| Sheath Material | PVC/XLPE/PE |
| Material Shape | Round Wire |
| Wire Core Material | Copper or Tinned Copper |
| Certification | ISO, CCC, CE, RoHS |
| Model | Instrument Cable |
| Brand | Henway |
| Quality | High Quality |
| Standard | ASTM, BS, as, DIN, CSA, IEC, GB/T |
| Pair No | 1-61pairs |
| Sample | Available |
| OEM/ODM | Yes |
| Transport Package | Wooden Drums, Steel-Wooden Drums, Steel Drums |
| Specification | Customized |
| Origin | China |
| HS Code | 8544492100 |
| Production Capacity | 10, 000, 000km Per Year |
| Package Size | 1.00cm * 1.00cm * 1.00cm |
| Package Gross Weight | 0.100kg |
| Applicable Standards | BS 5308, IEC60502-1, BS EN 50288-7,ANSI / ICEA S-73-532 or the standards agreed by both of the customers and us. |
| Conductor type | Stranded or solid (class 1, 2, and 5) |
| Nominal Cross Section Area | 0.5mm2 to 6mm2 |
| Pair No. | 1-61pairs |
| Conductor | Copper or tinned copper |
| Insulation | PVC /PE /XLPE |
| Individual Screen (optional) | Aluminum foil with drain wire, Copper wire braiding, Copper tape |
| Overall Screen | Aluminum foil with drain wire, Copper wire braiding, Copper tape |
| Armor (optional) | Steel Tape / Steel Wire |
| Sheath | PVC, PE, LSHF, or other special requirements |
| One Pair | Black/White Pair |
| Two Pairs and above | black/White Pairs with Numbers 1, 2….n or color. |
| Color of Sheath | Black, blue or customer designated. |
| Price | US$1.00 500 Meters(MOQ) |
| Supplier | Henan Henway Electric Co., Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | Low and Medium Voltage Cable |
|---|---|
| Insulation Material | PE |
| Sheath Material | PVC/XLPE/PE |
| Material Shape | Round Wire |
| Wire Core Material | Copper or Tinned Copper |
| Color of Sheath |
Additional data
| No.of pair×Nominal crosssection | 300V | 500V | ||||||
|---|---|---|---|---|---|---|---|---|
| Thicknessofinsulation | Approx.OverallDiameter | Approx mass | Thickness ofinsulation | Approx.OverallDiameter | Approx mass | |||
| PVC-insulated | PE-insulated | PVC-insulated | PE-insulated | |||||
| No/mm2 | mm | mm | Kg/Km | mm | mm | Kg/Km | ||
| 1×2×0.5 | 0.40 | 10.1 | 199 | 197 | 0.60 | 10.5 | 211 | 208 |
| 2×2×0.5 | 0.40 | 11 | 242 | 238 | 0.60 | 11.4 | 259 | 254 |
| 4×2×0.5 | 0.40 | 14.3 | 375 | 366 | 0.60 | 15.1 | 407 | 396 |
| 8×2×0.5 | 0.40 | 17.5 | 534 | 517 | 0.60 | 18.6 | 582 | 560 |
| 10×2×0.5 | 0.40 | 19.1 | 615 | 593 | 0.60 | 20.8 | 693 | 665 |
| 12×2×0.5 | 0.40 | 19.9 | 676 | 649 | 0.60 | 21.4 | 748 | 714 |
| 20×2×0.5 | 0.40 | 24.7 | 1053 | 1009 | 0.60 | 26.7 | 1176 | 1120 |
| 24×2×0.5 | 0.40 | 27.1 | 1225 | 1173 | 0.60 | 29.1 | 1348 | 1281 |
| 1×2×1.0 | 0.40 | 10.8 | 228 | 225 | 0.60 | 11.2 | 244 | 241 |
| 2×2×1.0 | 0.40 | 12.0 | 293 | 288 | 0.60 | 12.5 | 314 | 306 |
| 4×2×1.0 | 0.40 | 16.1 | 479 | 467 | 0.60 | 16.9 | 509 | 494 |
| 8×2×1.0 | 0.40 | 19.7 | 691 | 668 | 0.60 | 21.1 | 760 | 732 |
| 10×2×1.0 | 0.40 | 21.9 | 821 | 793 | 0.60 | 24.3 | 1042 | 1008 |
| 12×2×1.0 | 0.40 | 22.5 | 892 | 858 | 0.60 | 25.0 | 1130 | 1086 |
| 20×2×1.0 | 0.40 | 28.3 | 1430 | 1373 | 0.60 | 30.2 | 1548 | 1476 |
| 24×2×1.0 | 0.40 | 31.1 | 1658 | 1589 | 0.60 | 33.9 | 1989 | 1903 |
| 1×2×1.5 | 0.50 | 12.0 | 279 | 275 | 0.60 | 12.4 | 292 | 287 |
| 2×2×1.5 | 0.50 | 13.2 | 356 | 348 | 0.60 | 13.7 | 378 | 368 |
| 4×2×1.5 | 0.50 | 17.7 | 575 | 559 | 0.60 | 18.8 | 627 | 608 |
| 8×2×1.5 | 0.50 | 22.9 | 1001 | 970 | 0.60 | 24.4 | 1095 | 1057 |
| 10×2×1.5 | 0.50 | 25.6 | 1199 | 1161 | 0.60 | 27.3 | 1306 | 1259 |
| 12×2×1.5 | 0.50 | 26.6 | 1324 | 1278 | 0.60 | 28.1 | 1415 | 1358 |
| 20×2×1.5 | 0.50 | 33.1 | 2036 | 1959 | 0.60 | 35.0 | 2176 | 2080 |
| 24×2×1.5 | 0.50 | 36.3 | 2362 | 2269 | 0.60 | 38.5 | 2540 | 2426 |
Product description
The supplier lists this product. Its stated application is Construction, Overhead, Industrial, Power Station, Telecommunication. The listed model is Instrument Cable. The specifications below reflect the information publicly displayed on the listing. Model NO.: Instrument Cable. Insulation Material: PE. Sheath Material: PVC/XLPE/PE. Material Shape: Round Wire. Wire Core Material: Copper or Tinned Copper. Model: Instrument Cable.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Professional Low-Noise Audio Multi-Pair Cable Instrument Snake Cable?
The listed minimum order quantity is 500 meters. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Professional Low-Noise Audio Multi-Pair Cable Instrument Snake Cable cost?
The published price is US$1.00 per meter. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
Instrument Cable · US$1.00 · MOQ 500 Meters
