Professional Speaker 8” Neodymium 500 Watt Line Array Speaker.
Speaker Drivers, Woofers & Tweeters

Professional Speaker 8” Neodymium 500 Watt Line Array Speaker.

Model: 8NF65U1 Customization available Speaker Parts & Accessories
US$15.00 – 40.00
MOQ 1 Piece
Impedance
8 Ohm
Sensitivity
95 dB
Application
Stage
Activity
Passive
Operation Mode
No
Certification
CE, RoHS, FCC
Send Inquiry Full specifications

Specifications

Product nameProfessional Speaker 8” Neodymium 500 Watt Line Array Speaker.
CategorySpeaker Drivers, Woofers & Tweeters
CustomizationAvailable
ActivityPassive
Model NO.8NF65U1
Operation ModeNo
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating250 W
Program Power500 W
Frequency Range71-3500Hz
Voice Coil2.5''vc Ccaw in/out
Sensitivity95 dB
Impedance8 Ohm
MagnetNeodymium
ChassisRed Steel
Transport PackageCarton
Specification225 x 225 x 260 mm
OriginChina
HS Code8518290000
Production Capacity50000
PriceUS$15.00-40.00 1 Piece(MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

AES Power Rating250 W
Program Power500 W
Impedance8 Ohm

Additional data

Nominal diametermm (in.)210(8)
Nominal impedanceΩ8
Minimum impedanceΩ6.2
Program power (1)W500
AES Power rating(2)W250
Sensitivity (3)dB95
Frequency rangeHz71 ~ 3500
Voice coil diametermm (in.)65(2.5)
Chassis materialSteel
Magnet materialNeodymium
Magnet dimensions (ODxIDxh)mm64 x 10 x 10
Coil materialCCAW
Former materialGlass Fiber
Xmax(4)mm6
Xmech(5)mm10
Gap heightmm8
Voice coil Wingding heightmm16
DC resistanceReOhm5.2
Resonance frequencyFsHz71
Moving massMmsg30
ComplianceCmsmm/N0.14
Force factorBLN/A13.8
Mechanical Q-factorQms3.7
Electrical Q-factorQes0.36
Total Q-factorQts0.33
Equivalent air volumeVasI21
Voice coil InductanceLemH0.8
Diaphragm areaSdcm²227
Reference efficiencyEta 0%1.8
Net weightKg1.8
Multipack size (2) (W x D x H)mm225 x 225 x 260
Multipack weightKg3.9

Product description

The supplier lists this product. Its stated application is Stage. The listed model is 8NF65U1. The specifications below reflect the information publicly displayed on the listing. Noise: 0. Model NO.: 8NF65U1. AES Power Rating: 250 W. Program Power: 500 W. Frequency Range: 71-3500Hz. Sensitivity: 95 dB. Impedance: 8 Ohm.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Professional Speaker 8” Neodymium 500 Watt Line Array Speaker.?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Professional Speaker 8” Neodymium 500 Watt Line Array Speaker. cost?

The published price is US$15.00 – 40.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
