Professional Stereo Speaker Audio 2/3/4 Way Crossover 234XL
Crossovers, Voice Coils, Cones & Repair Parts

Professional Stereo Speaker Audio 2/3/4 Way Crossover 234XL

Model: 234XL Speaker Parts & Accessories
US$38.002–49 Pieces
US$36.0050–99 Pieces
US$34.00100–499 Pieces
US$32.00500+ Pieces
MOQ 2 Pieces
Application
PRO Audio
Noise
<95dB
Hi-Fi
Not Hi-Fi
Activity
Active
Operation Mode
PRO Audio
Certification
CE, RoHS, CCC, FCC
Send Inquiry Full specifications

Specifications

Product nameProfessional Stereo Speaker Audio 2/3/4 Way Crossover 234XL
CategoryCrossovers, Voice Coils, Cones & Repair Parts
Noise<95dB
Hi-FiNot Hi-Fi
ActivityActive
Model NO.234XL
Operation ModePRO Audio
ApplicationPRO Audio
CertificationCE, RoHS, CCC, FCC
THD<0.005%
Transport PackageCarton
Specification234XL
OriginCn
Production Capacity100000 Pieces/Year
SpecificationsInput Connectors
Ref+4 dBu, 22 kHz measurement bandwidth
Low/High45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Low/Mid45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting); High-Mid/High: 450 Hz to 9.6 kHz; Low-Mid/High-Mid: 450 Hz to 9.6 kHz
Multiplies the low-high(monolow/mid and high/mid) crossover frequency range of the front-panel markings by a factor of 1 or 10, one switch per channel
PriceUS$38.00 2-49 Pieces US$36.00 50-99 Pieces US$34.00 100-499 Pieces US$32.00 500+ Pieces
SupplierEnping Crcbox Audio Technology Co., Ltd
Data retrieved2026-10-23

Additional data

Input ConnectorsXLR
Input TypeElectronically balanced/unbalanced, RF filtered
Input ImpedanceBalanced >50k ohm, unbalanced >25k ohm
Max Input>+21dBu balanced or unbalanced
CMRR>40dB, typically >50dB at 1kHz
Output ConnectorsXLR
Output TypeImpedance-balanaced/unbalanced, RF filtered
Output ImpedanceBalanced 200 ohm, unbalanced 100 ohm
Max Output>+21dBu balanced/unbalanced into 2k or greater
Bandwidth20Hz to 20kHz, +/-0.5dB
Frequency Response< 3 Hz to > 90 kHz, +0/-3 dB
Signal to Noise RatioRef: +4 dBu, 22 kHz measurement bandwidth
Signal-to-Noise (Stereo Mode)>94dB (Low Output), >93dB (Mid Output), >92dB (High Output)
Signal-to-Noise (Mono Mode)>94dB (Low Output), >94dB (Low/Mid Output), >92dB (High/Mid Output)
Dynamic Range> 114 dB, unweighted, any output
THD+Noise< 0.004% at +4 dBu, 1 kHz; < 0.04% at +20 dBu, 1 kHz
Interchannel Crosstalk< -80 dB, 20 Hz to 20 kHz
Crossover Frequencies (Stereo Mode)Low/High: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Crossover Frequencies (Mono Mode)Low/Mid: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting); High-Mid/High: 450 Hz to 9.6 kHz; Low-Mid/High-Mid: 450 Hz to 9.6 kHz
Crossover Filter TypeLinkwitz-Riley, 24 dB/octave, state-variable
Low cut SwitchActivates 40 Hz Butterworth, 12 dB/octave high-pass filter, one switch per channel.
Phase Invert SwitchInverts the phase at the output, one switch per output.
x1 / x10 SwitchMultiplies the low-high(mono: low/mid and high/mid) crossover frequency range of the front-panel markings by a factor of 1 or 10, one switch per channel
Mode SwitchSelects stereo 2-way or mono 3-way operation and disables all LEDs for controls that are non-functional in the selected mode.
LF Sum SwitchSelects normal (stereo) or mono-summed low frequency operation and disables Ch 2's low output phase invert LED to indicate that this output is not operational in the LF sum mode.
IndicatorsStereo Operation (Green); Mono Operation (Yellow); Low Cut (Red-per channel); x10 (Green-per channel); Phase Invert (Red-per output)
Operating Voltage100-120 VAC 50/60 Hz; 120 VAC 60 Hz 230 VAC 50 Hz
Power Consumption15W
Power ConnectorIEC receptacle

Product description

The supplier lists this product. Its stated application is PRO Audio. The listed model is 234XL. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: 234XL.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Professional Stereo Speaker Audio 2/3/4 Way Crossover 234XL?

The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Professional Stereo Speaker Audio 2/3/4 Way Crossover 234XL cost?

The published price is US$32.00 – 38.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Customization depends on the manufacturer and order quantity. Describe what you need and we will confirm the options.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
