Raytalk Pnr Noise Canceling Microphon Headphone for Pilot Aviation Headset
Call Center, Business & Aviation Headsets

Raytalk Pnr Noise Canceling Microphon Headphone for Pilot Aviation Headset

Model: PH-100A-GA/PNR/SC Customization available Headphones & Earphones
US$80.00
MOQ 100 Pieces
Communication
Wired
Impedance
150 ohms (300 ohms each; wired in parallel)
Frequency Response
100Hz to 8 kHz
Sensitivity
95+/-5 dB SPL
Jack Diameter
3.5mm
Jack Type
L-shaped
Send Inquiry Full specifications

Specifications

Product nameRaytalk Pnr Noise Canceling Microphon Headphone for Pilot Aviation Headset
CategoryCall Center, Business & Aviation Headsets
CustomizationAvailable
Wire MaterialPVC
ColorBlack
Model NO.PH-100A-GA/PNR/SC
TypeElectret Earphone
CommunicationWired
UsagePortable Media Player
FunctionNoise-Canceling
Jack Diameter3.5mm
Jack TypeL-shaped
Noise Reduction Ratings24db
EarFoam Ear Seal/Gel Ear Seal
Ear PadsGel Ear Pads Optional
Microphone PlugPj-068( .206"F5.2 Phone Plug)
Earphone PlugPj-055( .25"F6.3 Phone Plug)
ApplicationAirplane/Airline/Pilot/Aircraft
Warranty12 Months
LogoCan Be Customized
Transport PackageStandard Airworthy Packing
Specification30*25*20
OriginChina
HS Code8529903000
Production Capacity10000
Overview1. GA use Dual plugs
Frequency Response100Hz to 8 kHz
Sensitivity95+/-5 dB SPL
Impedance150 ohms (300 ohms each; wired in parallel)
Rate Input100mW
Max. Input250mW
Operating Temperature-20 to 70 °C
CordageStraight cord from headset to molded plug, 150CM
Weights530g
Headset size range Height10 to 14 cm
BoomSpring tension boom
Element TypeNoise-canceling electret
Operating Voltage (supplied by aircraft )8-32 Volts DC
Matching Impedance150-1000 ohms
PriceUS$80.00 100 Pieces(MOQ)
SupplierRAYTALK COMMUNICATIONS LTD
Data retrieved2026-10-23

Available options

Wire MaterialPVC
ColorBlack
Jack Diameter3.5mm
Impedance
150 ohms (300 ohms eachwired in parallel)
Headset size range Height10 to 14 cm
Matching Impedance150-1000 ohms

Additional data

HeadphonesType: Dynamic (F50) Frequency Response:100Hz to 8 kHz Sensitivity:95+/-5 dB SPL (1 kHz, 1 mW input per earcup side) full volume on ear simulator Impedance:150 ohms (300 ohms each; wired in parallel) Rate Input:100mW Max. Input: 250mW
GeneralOperating Temperature: -20 to 70 °C Cordage: Straight cord from headset to molded plug, 150CM Intercom Connections Plug: Earphone Plug: PJ-055( .25"F6.3 phone plug) Microphone Plug:PJ-068( .206"F5.2 phone plug) Weights: 530g Headset size range Height: 10 to 14 cm Color: Green/Black/Pink/Red/Yellow/Blue/ White/Gray Boom: Spring tension boom
Microphone and amplifierElement Type: Noise-canceling electret Frequency Response:100Hz to 5 kHz Operating Voltage (supplied by aircraft ):8-32 Volts DC Matching Impedance: 150-1000 ohms Sensitivity:-33+/-4 dB (ref: 0dB SPL=20.0uPa at 1 kHz with 10 Vdc 150 ohms AC load)

Product description

The supplier lists this product as Electret Earphone. Its stated application is Portable Media Player. The listed model is PH-100A-GA/PNR/SC. Supplier-stated function: Noise-Canceling. The specifications below reflect the information publicly displayed on the listing. Wire Material: PVC. Model NO.: PH-100A-GA/PNR/SC. Noise Reduction Ratings: 24db. Frequency Response: 100Hz to 8 kHz. Sensitivity: 95+/-5 dB SPL. Impedance: 150 ohms (300 ohms each; wired in parallel). Matching Impedance: 150-1000 ohms.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Raytalk Pnr Noise Canceling Microphon Headphone for Pilot Aviation?

The listed minimum order quantity is 100 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Raytalk Pnr Noise Canceling Microphon Headphone for Pilot Aviation cost?

The published price is US$80.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
