Samll Show Sound Active Line Array Professional Speaker
PA, Stage & Line-Array Speakers

Samll Show Sound Active Line Array Professional Speaker

Model: CVR W-82C&W-15CP Customization available Speakers & Audio Systems
US$100.00 – 2,000.00
MOQ 1 Piece
Frequency Response
42Hz-150Hz±3dB(W-15bp)
Sensitivity
106dB(1W@1m)(W-15bp)
Type
Line Array Sub-Bass System(W-15bp)
Application
Commercial, Home
Noise
<95dB
Certification
CE, RoHS, CCC, FCC, ETL, MET
Send Inquiry Full specifications

Specifications

Product nameSamll Show Sound Active Line Array Professional Speaker
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Noise<95dB
ApplicationCommercial, Home
Model NO.CVR W-82C&W-15CP
CertificationCE, RoHS, CCC, FCC, ETL, MET
THD<0.005%
Place of OriginGuangdong, China (Mainla)
TypeLine Array Sub-Bass System(W-15bp)
Power Handling500W(RMS)1000W(Peak)(W-15bp)
Frequency Response42Hz-150Hz±3dB(W-15bp)
Sensitivity106dB(1W@1m)(W-15bp)
FinishBlack Paint
EnclosurePlywood
Transport PackageCartbox or Flight Case
SpecificationCE, ROHS, CCC, SGS, GMP
OriginChina Gd
HS Code8501510010
Production Capacity5000\\Month
OUR TEAM1. Any inquiries will be replied within 24 hours.
PriceUS$100.00-2,000.00 1 Piece(MOQ)
SupplierCVR PRO AUDIO CO.,LTD
Data retrieved2026-10-23

Available options

Power Handling500W(RMS)1000W(Peak)(W-15bp)

Additional data

ModelW-82B/W-15BP
TypeLine array system
Line array sub-bass system(W-15BP)
Frequency Response70Hz-20KHz±3dB
42Hz-150Hz±3dB(W-15BP)
Power handingLF 150W(RMS)300W(PEAK)
HF 60W(RMS)120W(PEAK)
500W(RMS)1000W(PEAK)(W-15BP)
SensitivityLF 95dB(1W@1M)
HF 108dB(1W@1M)
106dB(1W@1M)(W-15BP)
Max@S.P.LLF 117dB(PEAK/1M)
HF 126dB(PEAK/1M)
133dB(PEAK/1M)(W-15BP)
LF section1×8"(210mm) woofer
50mm(2in)coil
Components1×15"(380mm) woofer
100mm(4in)coil(W-15BP)
Nominal impedance8 ohm
8 ohm(W-15BP)
HF section1×1.75"compression driver
with 44mm titanium diaphragm
Output section2-channel
Dispersion pattern110°H×9°V
FinishWater-proof,wear-resistant textured black paint
Array designArrays of less than 3×W-82B will
provide poor dispersion control and
are neither recommended nor supported
Speaker cables1(+)1(-)Built in crossover
Rigging systemPlease refer to the W-82B user
manual before any operation
Input connectors2×NL4MP speakon
Recommend crossover70Hz-20kHz
45Hz-100Hz(W-15BP)
Dimensions514×235×460mm(W×H×D)
515×450×590mm(W×H×D)(W-15BP)
Package dimensions575×305×530mm/0.09cbm
585×520×660mm/0.2cbm(W-15BP)
EnclosurePU(W-82B)/plywood(W-15BP)
Net weight15kg (W-82B)/ 32kg (W-15BP)
Gross weight17kg (W-82B)/ 34kg (W-15BP)

Product description

The supplier lists this product as Line Array Sub-Bass System(W-15bp). Its stated application is Commercial, Home. The listed model is CVR W-82C&W-15CP. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: CVR W-82C&W-15CP. Power Handling: 500W(RMS)1000W(Peak)(W-15bp). Frequency Response: 42Hz-150Hz±3dB(W-15bp). Sensitivity: 106dB(1W@1m)(W-15bp).

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Samll Show Sound Active Line Array Professional Speaker?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Samll Show Sound Active Line Array Professional Speaker cost?

The published price is US$100.00 – 2,000.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
