Seeraudio Professional 2u Power Amplifier 2channels Analog Amplifier for DJ Stage
- Rated Power
- 20Hz-20kHz(+0/-0.5dB)
- Type
- Professional Amplifier
- Usage
- Hi-Fi, AV, KTV System, Professional Speaker
- Color
- Sliver
- Used For
- Professional
- Tube Type
- Transistor Amplifier
Specifications
| Product name | Seeraudio Professional 2u Power Amplifier 2channels Analog Amplifier for DJ Stage |
|---|---|
| Category | Speaker Amplifiers & Audio Processors |
| Model NO. | FA-5001 |
| Used For | Professional |
| Tube Type | Transistor Amplifier |
| Function | Post Amplifier |
| Sound Channel | 2.1 |
| Output Number | 2 |
| Voltage | AC 220V |
| Element Number | Push-Pull Amplifier |
| Conductive Mode | D |
| Output Circuit | Class H |
| S/N Ratio | 105dB |
| Input Sensitivity | 0.775V/1.0V/1.44V |
| Limiting Protection | Can Reach 4V |
| Rated Power | 20Hz-20kHz(+0/-0.5dB) |
| Conversion Rate | 40V/Us |
| Damping Coefficient | 550@8&Ohm |
| Signal to Noise Ratio | 105dB |
| Product Weight | 22.8kg |
| Packaging Weight | 23.8kg |
| Color | Sliver |
| Professional | Professional Amplifier |
| Transport Package | Carton |
| Specification | 483*450*88mm |
| Origin | Gunagzhou |
| HS Code | 8518400090 |
| Customization | Available |
| Type | Professional Amplifier |
| Usage | Hi-Fi, AV, KTV System, Professional Speaker |
| Price | Negotiable 1 set (MOQ) |
| Supplier | Guangzhou Seer Audio Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Voltage | AC 220V |
|---|---|
| Rated Power | 20Hz-20kHz(+0/-0.5dB) |
| Color | Sliver |
Additional data
| Model | FA-5001 |
|---|---|
| 8Ω output power/stereo | 2×1300W |
| 8Ωoutput power/stereo | 2×2000W |
| 4Ωoutput power/stereo | 2×2400W |
| 8Ωoutput power/bridging | 1×3900W |
| 4Ωoutput power/bridging | 1×4900W |
| Output circuit | Class H |
| Rated power | 20Hz-20KHz(+0/-0.5dB) |
| Conversion rate | ≥40V/us |
| Damping coefficient | >550@8Ω |
| Input impedance | 20KΩ(balanced)/10KΩ(unbalanced) |
| Phase response | >100dB@8Ω1KHz |
| Limiting protection | Can reach 4V |
| Signal to noise ratio (rated power 8Ω) | ≥105dB |
| Separation degree | >85dB@8Ω1KHz |
| Total harmonic distortion (half power) | <0.05%@8Ω1KHz |
| Intermodulation distortion (half power) | ≤0.2% |
| Input sensitivity | 0.775V/1.0V/1.44V |
| Input connector | 2× three core XLR female seat/2× three core XLR male seat |
| Output connector | 2×NL4FX four core audio connector red positive black negative terminal |
| Power connector | AC220V(50Hz-60Hz) |
| Control and indication/front panel | AC switch,pow power light(white to blue)SIG signal light(green)CLP distortion signal light(yellow)POR protection light(red) |
| Surface treatment | Black painted chassis, black painted/aluminum front panel |
| Protection system | DC, short circuit, overheating, soft start output/input overload protection |
| Cooling system | Intelligent temperature controlled continuous variable speed fan, with front to back air flow |
| Product volume | 0.05m³ |
| Product height | 2U |
| Product size(W×D×H) | 483×450×88mm |
| Packaging size(W×D×H) | 550×522×132mm |
| Product weight(kg) | 22.8kg |
| Packaging weight(kg) | 23.8kg |
Product description
The supplier lists this product as Professional Amplifier. Its stated application is Hi-Fi, AV, KTV System, Professional Speaker. The listed model is FA-5001. Supplier-stated function: Post Amplifier. The specifications below reflect the information publicly displayed on the listing. Model NO.: FA-5001. Input Sensitivity: 0.775V/1.0V/1.44V. Rated Power: 20Hz-20kHz(+0/-0.5dB). Signal to Noise Ratio: 105dB.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Seeraudio Professional 2u Power Amplifier 2channels Analog Amplifier?
The listed minimum order quantity is 1 set. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Seeraudio Professional 2u Power Amplifier 2channels Analog Amplifier cost?
The price is not publicly listed. Send an inquiry with your quantity and requirements to receive a quotation.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
