Single 15″ Two- Way Professional Sound Box PA Speaker
- Rated Power
- 400W RMS, 1600W Peak
- Impedance
- 8 Ohms Nominal
- Sensitivity
- 107db 1 Watt/1 Meter
- Usage
- Stage/DJ, Stadiums
- Amplification Type
- Passive
- Speaker Material
- Fiberglass
Specifications
| Product name | Single 15″ Two- Way Professional Sound Box PA Speaker |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Amplification Type | Passive |
| Speaker Material | Fiberglass |
| Model NO. | LT1564 |
| Usage | Stage/DJ, Stadiums |
| Structure | Two-Way Loudspeaker System |
| Function | Stage Loudspeaker |
| Frequency Response(-3db) | 80Hz-18kHz |
| Woofer | 1X15"(385mm)/3" Voice Coil Woofer |
| Driver | 1X1.4"(36mm)/3" Voice Coil Tweeter |
| Rated Power | 400W RMS, 1600W Peak |
| Sensitivity | 107db 1 Watt/1 Meter |
| Impedance | 8 Ohms Nominal |
| Maximum Spl | 133db Continuous, 139db Peak |
| Dispersion(-6db) | 60°×40° |
| Crossover Frequencies | 1.7kHz Passive |
| Transport Package | Carton Box |
| Specification | 675x675x872mm |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 5000PCS/Month |
| Applications | used for stadiums, outdoor projects |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Direct | 0086-(0)769-89820683 |
| Fax | 0086-(0)769-22781297 |
| Web | fdbaudiochina.en.made-in-china.com |
| Price | US$1.00-3,000.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Fiberglass |
|---|---|
| Rated Power | |
| Impedance | 8 Ohms Nominal |
Additional data
| MODEL | LT1064 | LT1564 |
|---|---|---|
| FREQUENCY RESPONSE(-3dB) | 90Hz-18kHz | 80Hz-18kHz |
| DRIVERS | 1×10"(250mm)/2.5" voice coil LF | 1×15"(385mm)/3"voice coil LF |
| 1×1"(25mm)/1.7"voice coil HF | 1×1.4"(36mm)/3"voice coil HF | |
| RATED POWER | 250W RMS,1000W peak | 400W RMS,1600W peak |
| SENSITIVITY | 103dB 1watt/1 meter | 107dB 1watt/1 meter |
| MAXIMUM SPL | 127dB continuous,133dB peak | 133dB continuous,139dB peak |
| IMPEDANCE | 8 ohms nominal | 8 ohms nominal |
| DISPERSION(-6dB) | 60°×40° | 60°×40° |
| CROSSOVER FREQUENCIES | 2.2kHz passive | 1.7kHz passive |
| INPUT CONNECTORS | 2×Speakon NL4 | 2×Speakon NL4 |
| PACKING SIZE | 547mm×547mm×730mm | 675mm×675mm×872mm |
| NET WEIGHT | 22.5 kg/pc | 35.8 kg/pc |
| GROSS WEIGHT | 26 kg/pc | 41 kg/pc |
Product description
The supplier lists this product. Its stated application is Stage/DJ, Stadiums. The listed model is LT1564. Supplier-stated function: Stage Loudspeaker. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Fiberglass. Model NO.: LT1564. Frequency Response(-3db): 80Hz-18kHz. Driver: 1X1.4"(36mm)/3" Voice Coil Tweeter. Rated Power: 400W RMS, 1600W Peak. Sensitivity: 107db 1 Watt/1 Meter. Impedance: 8 Ohms Nominal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
