Single Compact Vented 18″ Line Array Subwoofer Professional Speaker
- Rated Power
- 600W RMS, 2400W Peak
- Impedance
- 8 Ohms Nominal
- Sensitivity
- 99db 1 Watt/1 Meter
- Speaker Material
- Plywood
- Frequency Response(-3db)
- 40Hz-300Hz
- Woofer
- 1X18"(460mm)/4" Voice Coil Woofer
Specifications
| Product name | Single Compact Vented 18″ Line Array Subwoofer Professional Speaker |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Speaker Material | Plywood |
| Frequency Response(-3db) | 40Hz-300Hz |
| Model NO. | LA118B |
| Woofer | 1X18"(460mm)/4" Voice Coil Woofer |
| Rated Power | 600W RMS, 2400W Peak |
| Impedance | 8 Ohms Nominal |
| Sensitivity | 99db 1 Watt/1 Meter |
| Maximum Spl | 127db Continuous, 133db Peak |
| Transport Package | Carton Box |
| Specification | 895x795x615mm |
| Origin | Dongguan, China |
| HS Code | 8518210000 |
| Production Capacity | 3000PCS/Month |
| Applications | 1.outdoor moving performance |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Web | fdbaudiochina.en.made-in-china.com |
| Horizontal coverage | 100° |
| Price | US$535.00-4,275.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Plywood |
|---|---|
| Rated Power | |
| Impedance | 8 Ohms Nominal |
Additional data
| MODEL | LA5312 ( Full range speaker) |
|---|---|
| FREQUENCY RESPONSE(-3dB) | 50Hz-18kHz |
| DRIVERS | 1×12"(300mm)/3"voice coil LF |
| 2×5"(132mm)/1.5"voice coil MF | |
| 2×1"(25mm)/1.7"voice coil HF | |
| RATED POWER | 400W RMS,1600W peak |
| SENSITIVITY | 100dB 1watt/1 meter |
| MAXIMUM SPL | 126 dB continuous,132 dB peak |
| IMPEDANCE | 8 ohms nominal |
| DISPERSION(-6dB) | Horizontal coverage:100° |
| Varies, depending on array length and configuration | |
| CROSSOVER FREQUENCIES | 800Hz, 2.2kHz passive |
| INPUT CONNECTORS | 2×Speakon NL8 |
| PACKING SIZE | 775mm×600mm×990mm(Flight case/Pair) |
| 662mm×497mm×822mm | |
| NET WEIGHT | 42.7 kg/pc |
| GROSS WEIGHT | 122 kg/(Flight case/Pair) |
| 46.2 kg/pc(Carton/pc) | |
| MODEL | LA118B (Subwoofer) |
| FREQUENCY RESPONSE(-3dB) | 40Hz-300Hz |
| DRIVERS | 1×18"(460mm)/4"voice coil LF |
| RATED POWER | 600W RMS,2400W peak |
| SENSITIVITY | 99dB 1watt/1 meter |
| MAXIMUM SPL | 127dB continuous,133 dB peak |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKING SIZE | 775m×860mm×775mm(Flight case/pc) |
| 895mm×795mm×615mm | |
| NET WEIGHT | 71.5 kg/pc |
| GROSS WEIGHT | 108.5 kg/(Flight case/pc) |
| 77.5 kg/pc |
Product description
The supplier lists this product. The listed model is LA118B. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Plywood. Frequency Response(-3db): 40Hz-300Hz. Model NO.: LA118B. Rated Power: 600W RMS, 2400W Peak. Impedance: 8 Ohms Nominal. Sensitivity: 99db 1 Watt/1 Meter.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Single Compact Vented 18″ Line Array Subwoofer Professional Speaker?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Single Compact Vented 18″ Line Array Subwoofer Professional Speaker cost?
The published price is US$535.00 – 4,275.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
LA118B · US$535.00 – 4,275.00 · MOQ 1 Piece
