Speaker Line Array Factory Wholesale Dual 8 Inch 3 Way Active Line Array Speaker
PA, Stage & Line-Array Speakers

Speaker Line Array Factory Wholesale Dual 8 Inch 3 Way Active Line Array Speaker

Model: MX-L6-A Customization available Speakers & Audio Systems
US$500.00 – 800.00
MOQ 1 Piece
Type
3 Way Active Line Array
Application
Commercial, Home
Color
Black
Noise
<95dB
Hi-Fi
Hi-Fi
Activity
Active
Send Inquiry Full specifications

Specifications

Product nameSpeaker Line Array Factory Wholesale Dual 8 Inch 3 Way Active Line Array Speaker
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
Noise<95dB
Hi-FiHi-Fi
Model NO.MX-L6-A
ActivityActive
Operation ModeWire / Remote Control
Speaker System5.1 Channel
Speaker MaterialMetal
ApplicationCommercial, Home
CertificationCE, RoHS
MonitorNo
THD<0.03%
Frequency Range (Hz)52Hz-20kHz
Type3 Way Active Line Array
Active Line ArrayClass D Amplifier Module
on-Board DSPEnable for Remote Control
Warranty2 Years
ColorBlack
Transport PackageCarton or Flight Case Packing
Specification719*420*262mm
OriginGuangdong, China
Production Capacity50000
L6-Aactive 3-way double 8" line-array,
HF2x1.4"Neo,4Ohm 160W,Original Celestion Driverfrom UK ,neodynium
MF4x4" Neo,8Ohm,200W,Original Celestion Driver from UK ,neodynium
LF2x8"Neo,120W ,8Ohm,neodynium
With 3 channel amplifier,Class-D,output power500W+600W+600W/8Ohm,with built-in DSP made in Germany
PriceUS$500.00-800.00 1 Piece(MOQ)
SupplierGuangzhou MINGXUAN Stage Light Equipment CO.,LTD
Data retrieved2026-10-23

Available options

Speaker MaterialMetal
ColorBlack

Additional data

Configuration2*8"LF Neo(neo )+4*4"MF(neo Celestion from UK)+2* 1.4"Hi Neo (neo Celestion from UK)
Power(AES/Peak)LF:400W/800W MF:200W/400W HF:120W/160W
Impedance for driverLF4Ω /MF8Ω /HF4Ω
Impedance for amp20KΩ
Rated Maximum SPL135dB
Dispersion angle(V x H)H120°x V10°
Input Impendance20KΩ
Input Sensitivity0.775V
Amplifier Output Power500W+ 900W+ 1200W/8ohm
Power ConnectorPower Con
Operating Voltage90~ 120V/190~ 240V
Damping Factor≥400
Weight25Kg
Shipping Size719*420* 262mm

Product description

The supplier lists this product as 3 Way Active Line Array. Its stated application is Commercial, Home. The listed model is MX-L6-A. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: MX-L6-A. Speaker Material: Metal. Frequency Range (Hz): 52Hz-20kHz. With 3 channel amplifier,Class-D,output power: 500W+600W+600W/8Ohm,with built-in DSP made in Germany.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Speaker Line Array Factory Wholesale Dual 8 Inch 3 Way Active Line?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Speaker Line Array Factory Wholesale Dual 8 Inch 3 Way Active Line cost?

The published price is US$500.00 – 800.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
