Tact Tq10 2+1 Subwoofer High Quality Neodymium Magnet Passive Line Array Speaker
- Frequency Response
- 60Hz-18kHz
- Sensitivity
- 104dB Spl 1W/1m
- Application
- Commercial, Home, Outdoor
- Noise
- <95dB
- Hi-Fi
- Not Hi-Fi
- Activity
- Passive
Specifications
| Product name | Tact Tq10 2+1 Subwoofer High Quality Neodymium Magnet Passive Line Array Speaker |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Not Hi-Fi |
| Model NO. | TQ10 |
| Activity | Passive |
| Operation Mode | Wire / Remote Control |
| Speaker System | Optional Combination |
| Speaker Material | Wood |
| Application | Commercial, Home, Outdoor |
| Certification | CE |
| Monitor | No |
| THD | 0.005%-0.01% |
| Weight | 16.1kg |
| Item Name | Single 10inch Line Array Speaker |
| Power Rating | 300W |
| Sensitivity | 104dB Spl 1W/1m |
| Frequency Range | 55Hz-20kHz |
| Frequency Response | 60Hz-18kHz |
| Hf Voice Coil | 2X44mm, Neodymium |
| Lf Voice Coil | 65mm, Neodymium |
| Nominal Impedence | 16 Ohms |
| Transport Package | Array Speaker with EPE in 7mm Thickness Cartons |
| Specification | 530mm x354mm x330mm |
| Origin | China |
| HS Code | 8518220000 |
| Production Capacity | 1000pieces/Month |
| Package Size | 87.00cm * 70.00cm * 110.00cm |
| Package Gross Weight | 90.000kg |
| Company Information | TACT factory with total 15,000 square meters production area, 5 production lines, 120 employees. TACT professional audio is a reliable manufacturer offer a range of products of audio systems. Includes professional stage speaker, pa speakers, meeting speaker, line array speaker, power amplifier, speaker processor, microphone, mixer. We have been enjoyed the good reputation in over 50 countries. |
| Price | US$1,081.00 4-9 Sets US$991.00 10-19 Sets US$901.00 20+ Sets |
| Supplier | Enping TACT Pro Audio Equipment Co.,Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|---|
| Power Rating | 300W |
Additional data
| Basic parameters | |
|---|---|
| Model | TQ10 |
| Name | Single 10 inch passive line array speaker |
| Frequency range | 55Hz-20kHz |
| Frequency response | 60Hz-18kHz(±3dB) |
| Sensitivity | 107dB SPL 1w/1m |
| Maximum SPL @ 1 m | 136dB SPL |
| High frequency | 2*44mm (neodymium ND magnet) |
| Low frequency | 75mm voice coil (neodymium ND magnet) |
| Coverage pattern | 110°x15° |
| Dimensions(HxWxD) | 280mm 540mm x 375mm |
| Material | 15mm thickness birch plywood cabinet |
| Net weight(each) | 16Kg |
| Model | TQ18B |
| Name | Single 18 inch subwoofer |
| Frequency range | 40Hz-400Hz |
| Frequency response | 40Hz-150Hz(±3dB) |
| Sensitivity | 102db SPL 1w/1m |
| Power rating | 650W |
| Maximum SPL @ 1 m | 130dB SPL |
| Low frequency | 220mm magnet/100mm voice coil |
| Dimensions(HxWxD) | 650mm x 530mm x 600mm |
| Input connector | 2x Neutrik® NL4MP |
| Material | 18mm thickness birch plywood cabinet |
Product description
The supplier lists this product. Its stated application is Commercial, Home, Outdoor. The listed model is TQ10. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: TQ10. Speaker Material: Wood. Power Rating: 300W. Sensitivity: 104dB Spl 1W/1m. Frequency Range: 55Hz-20kHz. Frequency Response: 60Hz-18kHz.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Tact Tq10 2+1 Subwoofer High Quality Neodymium Magnet Passive Line?
The listed minimum order quantity is 4 sets. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Tact Tq10 2+1 Subwoofer High Quality Neodymium Magnet Passive Line cost?
The published price is US$901.00 – 1,081.00 per set, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
TQ10 · US$901.00 – 1,081.00 · MOQ 4 Sets
