Tc9044L-50 Coaxial Hf/Mf Compression Driver with 2-Inch Throat
Speaker Drivers, Woofers & Tweeters

Tc9044L-50 Coaxial Hf/Mf Compression Driver with 2-Inch Throat

Model: TC9044L-50 Customization available Speaker Parts & Accessories
US$148.0030–99 Pieces
US$142.00100–499 Pieces
US$135.00500+ Pieces
MOQ 30 Pieces
Application
Professional Audio
Activity
Compatible
Operation Mode
Compatible
Speaker System
Compatible
Speaker Material
Compatible
Certification
CE, RoHS
Send Inquiry Full specifications

Specifications

Product nameTc9044L-50 Coaxial Hf/Mf Compression Driver with 2-Inch Throat
CategorySpeaker Drivers, Woofers & Tweeters
Model NO.TC9044L-50
ActivityCompatible
Operation ModeCompatible
Speaker SystemCompatible
Speaker MaterialCompatible
ApplicationProfessional Audio
CertificationCE, RoHS
MonitorCompatible
THD<0.005%
AES Power HandlingMf:120W Above 400Hz; Hf:60W Above 6300Hz
Voice Coil DiameterMiddle:88.9mm; High:44.3mm
Diaphragm MaterialPolymer
Throat Diameter50mm (2in)
Transport PackageCarton
SpecificationNeodymium, NW 2.4kg
OriginChina
HS Code85182900
Production Capacity20000pieces/Year
Package Size47.00cm * 35.00cm * 12.00cm
Package Gross Weight15.500kg
Lead Time7 days (1 - 30 Pieces) To be negotiated ( > 30 Pieces)
CustomizationAvailable
NoiseMiddle:115dB; High:115dB
Hi-FiPA
KEY FEATURESMiddle 115dB & High 115dB 1W/1m sensitivity
Middle6.4Ω at 3500Hz
High6.8Ω at 10000Hz
Middle&HighCopper Clad Aluminum
NOTES1
Our quality management system is certified under ISO 90012015, and we hold multiple invention patents.
PriceUS$148.00 30-99 Pieces US$142.00 100-499 Pieces US$135.00 500+ Pieces
SupplierDongguan Weijiasheng Technology Co., Ltd.
Data retrieved2026-10-23

Available options

Speaker MaterialCompatible
AES Power Handling
Mf:120W Above 400HzHf:60W Above 6300Hz
Voice Coil Diameter
Middle:88.9mmHigh:44.3mm
Diaphragm MaterialPolymer
Throat Diameter50mm (2in)

Additional data

Part NumberTC9044L-50
Throat Diameter50mm (2in)
Nominal ImpedanceMiddle:8Ω
High:8Ω
Minimum ImpedanceMiddle:6.4Ω at 3500Hz
High:6.8Ω at 10000Hz
AES Power Handling2Middle:120W IEC above 400Hz
High:60W IEC above 6300Hz
Maximum Power Handling3Middle:240W IEC above 500Hz
High:120W IEC above 7000Hz
(1W/1m) Sensitivity (1W/1m)4Middle:115dB
High:115dB
Recommended Crossover5400Hz
Middle/High Crossover56300Hz
Frequency RangeMiddle:300Hz-7000Hz
High:6000Hz-18000Hz
Voice Coil DiameterMiddle:88.9mm
High:44.3mm
Winding MaterialMiddle&High:Copper Clad Aluminum(2 layers in and outside)
Former MaterialMiddle&High:Kapton
Flux DensityMiddle:1.9T
High:1.9T
Diaphragm MaterialMiddle&High:Polymer
Phase Plug MaterialMiddle:Plastic
High:Aluminum
Cover MaterialCast Aluminum
Magnet MaterialMiddle&High:Neodymium
Net Weight2.4kg

Product description

The supplier lists this product. Its stated application is Professional Audio. The listed model is TC9044L-50. The specifications below reflect the information publicly displayed on the listing. Model NO.: TC9044L-50. Speaker Material: Compatible. AES Power Handling: Mf:120W Above 400Hz; Hf:60W Above 6300Hz. Diaphragm Material: Polymer. Noise: Middle:115dB; High:115dB.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Tc9044L-50 Coaxial Hf/Mf Compression Driver with 2-Inch Throat?

The listed minimum order quantity is 30 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Tc9044L-50 Coaxial Hf/Mf Compression Driver with 2-Inch Throat cost?

The published price is US$135.00 – 148.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
