Th312 2X12 Inch Full Range Speaker Cabinet for Theatres and Cinemas 2X12 ′ Full Range Speaker Cabinet
- Rated Power
- 600W RMS, 2400W Peak
- Impedance
- 4 Ohms Nominal
- Sensitivity
- 103dB 1 Watt/1 Meter
- Application
- Commercial
- Activity
- Passive
- Speaker Material
- Plywood
Specifications
| Product name | Th312 2X12 Inch Full Range Speaker Cabinet for Theatres and Cinemas 2X12 ′ Full Range Speaker Cabinet |
|---|---|
| Category | Grilles, Cabinets & Enclosures |
| Customization | Available |
| Activity | Passive |
| Speaker Material | Plywood |
| Model NO. | TH312 /TH312A |
| Application | Commercial |
| Certification | CE, RoHS, ISO9001:2008 |
| Frequency Response(-3dB) | 70Hz-18kHz |
| Woofer | 2X12"(300mm)/3" Voice Coil Woofer |
| Driver | 1X1.4"(36mm)/3" Voice Coil Tweeter |
| Rated Power | 600W RMS, 2400W Peak |
| Sensitivity | 103dB 1 Watt/1 Meter |
| Impedance | 4 Ohms Nominal |
| Maximum Spl | 131dB Continuous, 137dB Peak |
| Dispersion(-6dB) | 60*40 |
| Crossover Frequencies | 1.3kHz Passive |
| Certificate | CE, RoHS, CCC |
| Transport Package | Carton Box |
| Specification | 530x530x795mm |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 5000PCS/Month |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Web | fdbaudiochina.en.made-in-china.com |
| Price | US$653.00-7,270.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Plywood |
|---|---|
| Rated Power | |
| Impedance | 4 Ohms Nominal |
Product description
The supplier lists this product. Its stated application is Commercial. The listed model is TH312 /TH312A. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Plywood. Model NO.: TH312 /TH312A. Frequency Response(-3dB): 70Hz-18kHz. Driver: 1X1.4"(36mm)/3" Voice Coil Tweeter. Rated Power: 600W RMS, 2400W Peak. Sensitivity: 103dB 1 Watt/1 Meter. Impedance: 4 Ohms Nominal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Th312 2X12 Inch Full Range Speaker Cabinet for Theatres and Cinemas?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Th312 2X12 Inch Full Range Speaker Cabinet for Theatres and Cinemas cost?
The published price is US$653.00 – 7,270.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
TH312 /TH312A · US$653.00 – 7,270.00 · MOQ 1 Piece
