Three-Way Single 15″ Loudspeaker System
- Rated Power
- 400W RMS, 1600W Peak
- Impedance
- 8 Ohms Nominal
- Sensitivity
- 99db 1 Watt/1 Meter
- Usage
- Stage/DJ, Multi-Purpose Hall, Moving Performance, Clubs
- Amplification Type
- Passive
- Speaker Material
- Plywood
Specifications
| Product name | Three-Way Single 15″ Loudspeaker System |
|---|---|
| Category | Other Speakers & Sound Systems |
| Customization | Available |
| Amplification Type | Passive |
| Speaker Material | Plywood |
| Model NO. | U153II |
| Usage | Stage/DJ, Multi-Purpose Hall, Moving Performance, Clubs |
| Structure | Two-Way Loudspeaker System |
| Function | Stage Loudspeaker |
| Frequency Response(-3db) | 45Hz-20kHz |
| Woofer | 1X15"(385mm)/3" Voice Coil Woofer |
| Mf | 1X6.5"(165mm)/2" Voice Coil Mf |
| Driver | 1X1"(25mm)/1.4" Voice Coil Tweeter |
| Rated Power | 400W RMS, 1600W Peak |
| Sensitivity | 99db 1 Watt/1 Meter |
| Impedance | 8 Ohms Nominal |
| Maximum Spl | 125db Continuous, 131db Peak |
| Dispersion(-6db) | 65°X40° |
| Crossover Frequencies | 800kHz, 2.5kHz Passive |
| Transport Package | Carton Box |
| Specification | 430x470x760mm |
| Origin | Dongguan, China |
| HS Code | 8518220000 |
| Production Capacity | 5000PCS/Month |
| Applications | 1.Multi-purpose Halls |
| Factory Introduction | FDB Audio Manufacture Co., Ltd is specialized in researching, developing and manufacturing in PRO audio products. The main products are professional transducers(HF driver & woofer), speaker cabinets and electronic products like amplifiers and processors. |
| Direct | 0086-(0)769-89820683 |
| Fax | 0086-(0)769-22781297 |
| Web | fdbaudiochina.en.made-in-china.com |
| Price | US$1.00-3,000.00 1 Piece(MOQ) |
| Supplier | DONGGUAN FDB AUDIO MANUFACTURE CO .,LTD |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Plywood |
|---|---|
| Rated Power | |
| Impedance | 8 Ohms Nominal |
Additional data
| FREQUENCY RESPONSE(-3dB) | 45 Hz-20kHz |
|---|---|
| DRIVERS | 1×12"(200mm)/3"voice coil LF |
| 1×6.5"(165mm)/2"voice coil MF | |
| 1x1"(25mm)/1.4"voice coil HF | |
| RATED POWER | 400W RMS,1600W peak |
| SENSITIVITY | 99dB 1watt/1 meter |
| MAXIMUM SPL | 125dB continuous,131dB peak |
| IMPEDANCE | 8 ohms nominal |
| DISPERSION(-6dB) | 65°×40° |
| CROSSOVER FREQUENCIES | 800Hz, 2.5kHz passive |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKING SIZE | 565mm×535mm×865mm |
| NET WEIGHT | 32kg/pc |
| GROSS WEIGHT | 36 kg/pc |
Product description
The supplier lists this product. Its stated application is Stage/DJ, Multi-Purpose Hall, Moving Performance, Clubs. The listed model is U153II. Supplier-stated function: Stage Loudspeaker. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Plywood. Model NO.: U153II. Frequency Response(-3db): 45Hz-20kHz. Driver: 1X1"(25mm)/1.4" Voice Coil Tweeter. Rated Power: 400W RMS, 1600W Peak. Sensitivity: 99db 1 Watt/1 Meter. Impedance: 8 Ohms Nominal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Three-Way Single 15″ Loudspeaker System?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Three-Way Single 15″ Loudspeaker System cost?
The published price is US$1.00 – 3,000.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
U153II · US$1.00 – 3,000.00 · MOQ 1 Piece
