TM90-50 Middle Frequency Compression Driver
- Application
- Professional Audio
- Noise
- 115dB
- Hi-Fi
- PA
- Activity
- Compatible
- Operation Mode
- Compatible
- Speaker System
- Compatible
Specifications
| Product name | TM90-50 Middle Frequency Compression Driver |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Noise | 115dB |
| Hi-Fi | PA |
| Model NO. | TM90L-50 |
| Activity | Compatible |
| Operation Mode | Compatible |
| Speaker System | Compatible |
| Speaker Material | Compatible |
| Application | Professional Audio |
| Certification | CE, RoHS |
| Monitor | Compatible |
| THD | <0.005% |
| AES Power Handling | 150W Above 400Hz |
| Voice Coil Diameter | 88.9mm |
| Diaphragm Material | Polymer |
| Throat Diameter | 50mm (2in) |
| Transport Package | Carton |
| Specification | Neodymium, NW 1.9kg |
| Origin | China |
| HS Code | 85182900 |
| Production Capacity | 30000pieces/Year |
| Package Size | 47.00cm * 35.00cm * 12.00cm |
| Package Gross Weight | 12.500kg |
| Lead Time | 7 days (1 - 24 Pieces) To be negotiated ( > 24 Pieces) |
| KEY FEATURES | 115dB 1W/1m sensitivity |
| NOTES | 1 |
| Our quality management system is certified under ISO 9001 | 2015, and we hold multiple invention patents. |
| Price | US$103.00 30-99 Pieces US$98.00 100-499 Pieces US$94.00 500+ Pieces |
| Supplier | Dongguan Weijiasheng Technology Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Compatible |
|---|---|
| AES Power Handling | 150W Above 400Hz |
| Voice Coil Diameter | 88.9mm |
| Diaphragm Material | Polymer |
| Throat Diameter | 50mm (2in) |
Additional data
| Part Number | TM90L-50 |
|---|---|
| Throat Diameter | 50mm (2in) |
| Nominal Impedance | 8Ω |
| Minimum Impedance | 6.4Ω at 3500Hz |
| AES Power Handling2 | 150W above 400Hz |
| Maximum Power Handling3 | 300W above 500Hz |
| (1W/1m) Sensitivity (1W/1m)4 | 115dB |
| Recommended Crossover5 | 400Hz |
| Frequency Range | 300Hz-7kHz |
| Voice Coil Diameter | 88.9mm |
| Winding Material | Copper Clad Aluminum (2 layers in and outside) |
| Former Material | Kapton |
| Flux Density | 1.9T |
| Diaphragm Material | Polymer |
| Phase Plug Material | Plastic |
| Cover Material | Cast Aluminum |
| Magnet Material | Neodymium |
| Net Weight | 1.9kg |
Product description
The supplier lists this product. Its stated application is Professional Audio. The listed model is TM90L-50. The specifications below reflect the information publicly displayed on the listing. Noise: 115dB. Model NO.: TM90L-50. Speaker Material: Compatible. AES Power Handling: 150W Above 400Hz. Diaphragm Material: Polymer.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for TM90-50 Middle Frequency Compression Driver?
The listed minimum order quantity is 30 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does TM90-50 Middle Frequency Compression Driver cost?
The published price is US$94.00 – 103.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
TM90L-50 · US$94.00 – 103.00 · MOQ 30 Pieces
