Transparent PVC Insulated Rvb-Speaker Wire with Low Voltage Specifications
Speaker Wire & Speaker Cables

Transparent PVC Insulated Rvb-Speaker Wire with Low Voltage Specifications

Model: Transparent PVC 8fig Customization available Cables, Adapters & Audio Electronics
US$0.05 – 0.15
MOQ 5,000 Meters
Type
Speaker Wire
Application
Speaker, Microphone, Game Player, Building
Color
Transparent
Species
Speaker Wire
Connector
RCA
Material Shape
Twin Sheath
Send Inquiry Full specifications

Specifications

Product nameTransparent PVC Insulated Rvb-Speaker Wire with Low Voltage Specifications
CategorySpeaker Wire & Speaker Cables
CustomizationAvailable
ApplicationSpeaker, Microphone, Game Player, Building
ColorTransparent
Model NO.Transparent PVC 8fig
TypeSpeaker Wire
SpeciesSpeaker Wire
ConnectorRCA
Material ShapeTwin Sheath
Wire Core MaterialBare Copper Wire
CertificationRoHS, CE, ISO9001
BrandOEM Produce
Transport Package100m Coil
Specification0.5, 0.75, 1.0, 1.5, 2.5mm Square
OriginHangzhou, China
HS Code8544491100
Production Capacity60000boxes/Year
Package Size45.00cm * 45.00cm * 35.00cm
Package Gross Weight15.000kg
Easy to InstallClass 5 flexible conductor stranding for easy installation
Extremely FlexiblePVC insulation allows for a small bending radius
Standard227IEC 42
ConstructionTined copper conductor, PE insulated, bare copper conductor, PVC insulated, twin parallel
Voltage300/500V
Core colorcolorful, transparant, black, white, red and black
OEM Services100 Coils/Reel
FocusProfessional Cables Manufacturer since 2012
Capacity3,000 boxes/month
ClientsSupplying overseas clients
Factory AdvantagesOther Products
why you might choose figure 8 low voltage cablesFigure 8 cable comprises of 2 individually insulated cables joined by a small segment of the outer sheath. It is called figure 8 because of its cross sectional appearance. The cables can be easily separated where required. Typically one core has a coloured tracer painted along its length to aid identification and polarisation. Figure 8 cable has a wide range of applications including audio, speaker, security Alarm and mains.
Durability and Weather ResistanceMany figure 8 cables are designed for outdoor use and feature a durable jacket that can withstand harsh weather conditions, including UV exposure and moisture.
Ease of InstallationThe figure 8 design allows for a straightforward one-step installation, using standard hardware and methods.
Elimination of SaggingThe inclusion of a messenger wire or other support elements helps to prevent sagging, which can be a problem with standard cables, especially in aerial applications.
VersatilityFigure 8 cables are used in a wide range of applications, from telephone lines and security systems to data transmission and even garden lighting.
PriceUS$0.05-0.15 5,000 Meters(MOQ)
SupplierHangzhou Aite Cable Co., Ltd
Data retrieved2026-10-23

Available options

ColorTransparent
Material ShapeTwin Sheath
Wire Core MaterialBare Copper Wire
ConnectorRCA
Voltage300/500V
Core color
colorfultransparantblackwhitered and black

Additional data

Attribute NameAttribute Value
Material outer sheathTwin sheathed PVC
Material Inner ConductorTCCA(Silver color)
Core identificationColor/edge strip
Color outer sheathTransparent/ Blue
Number of cores2 cores Figure 8 shape
Nominal voltage UO250V
Nominal cross section conductor0.75mm²
Length100M or customized
Cable height approx.2.8 mm
Cable width approx.5.7 mm
Conductor categoryClass 5 = Flexible
Voltage32V - Not suitable for connection to mains
Speaker Cable and Wire
Standard: 227IEC 42
Application: be used in connecting for audio appliances, home appliances, small electric tools and instruments
Construction: Tined copper conductor, PE insulated, bare copper conductor, PVC insulated, twin parallel
Voltage: 300/500V
Core color: colorful, transparant, black, white, red and black
Norminal Area(mm²)Number of Cores (mm)Thickness of Insulation (mm)Jacket Outer Diameter (mm)
2Cores 8Figure2x0.5063/0.100.702.20x4.40
2x0.7598/0.100.702.40x4.80
2x1.007x18/0.100.802.60x5.20
2x1.57x27/0.100.903.10x6.20
2x2.007x36/0.101.003.90x7.80
2x2.57x45/0.101.204.20x8.40
2x4.007x72/0.101.304.80x9.60
2x0.5016/0.200.702.20x4.40
2x0.7524/0.200.702.40x4.80
2x1.0032/0.200.802.60x5.20
2x1.548/0.200.903.10x6.20

Product description

The supplier lists this product as Speaker Wire. Its stated application is Speaker, Microphone, Game Player, Building. The listed model is Transparent PVC 8fig. The specifications below reflect the information publicly displayed on the listing. Model NO.: Transparent PVC 8fig. Connector: RCA. Material Shape: Twin Sheath. Wire Core Material: Bare Copper Wire.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for Transparent PVC Insulated Rvb-Speaker Wire with Low Voltage?

The listed minimum order quantity is 5,000 meters. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does Transparent PVC Insulated Rvb-Speaker Wire with Low Voltage cost?

The published price is US$0.05 – 0.15 per meter. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
