Vrx932lap Powered Line Array Audio Speaker System
- Type
- Active
- Application
- Commercial
- Color
- Black
- Activity
- Active
- Operation Mode
- Wire / Remote Control
- Speaker System
- 2 Way Full Frequency
Specifications
| Product name | Vrx932lap Powered Line Array Audio Speaker System |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Model NO. | VRX932 |
| Activity | Active |
| Operation Mode | Wire / Remote Control |
| Speaker System | 2 Way Full Frequency |
| Speaker Material | Plywood |
| Application | Commercial |
| Certification | CE, FCC |
| Monitor | No |
| THD | <0.005% |
| Model | Vrx932lap |
| Type | Active |
| Color | Black |
| Hf | 2407 Neodymium Tweeter |
| Lf | 2262HPL/2268HPL Neodymium Woofer |
| Finish | Environmental Waterproof |
| Bi-AMP | Bi-AMP Type |
| Amplifier | with Inside Amplifier |
| Grille | Punched |
| Condition | New |
| Transport Package | Packaged in Carton Case or Flight Case |
| Specification | 70*54*44cm |
| Origin | China |
| HS Code | 8518220000 |
| Production Capacity | 200PCS/Month |
| Package Size | 54.00cm * 44.00cm * 72.00cm |
| Package Gross Weight | 29.000kg |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Hi-Fi |
| Revelant Collocation | 1.VRX918SP active subwoofer |
| Key Features | 1. |
| User selectable | 120V/240V (-15%,+10%) |
| Price | US$539.00 20 Pieces (MOQ) |
| Supplier | Guangzhou Skytone Audio Co., Limited |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Plywood |
|---|---|
| Color | Black |
Additional data
| Model | VRX932LAP |
|---|---|
| Frequency Range(-10dB) | 55Hz-20kHz |
| Frequency Response(±3dB) | 65Hz-20kHz |
| Coverage Pattern | 100*15 nominal |
| Maximum Peak Output | 115B SPL at 1m |
| LF Driver | 1*2262HPL 305MM (12in) dual voice coil Differential Driver woofer with nenodymium-magnet |
| HF Driver | 3*2408H 38mm(1.5in) voice coil neodymium compression driver |
| Nominal Impedance | LF:8ohms HF:8ohms |
| DPC-2 Intermal Amplification Output (at nominal load) | 1600 Watts Peak, 800 Watts Continuous |
| DPC-2 Output as (Continuous IEC shaped pink noise into rated load impedance) | LF: 800 Watts,HF: 120Watts |
| Audio Input Connector | XLR with loop through |
| User Controls | Input Attenuator (0-16dB) ACS (Array Configuration Selector) HF level adjustment (+3dB ,0dB,-3dB) |
| Signal Processing | DSP based, resident in Input Module |
| System Management | DSP based limiters for mechnical and thermal protection. |
| AC Power Operating Range | 90-132 VAC or 216-264 VAC, 50/60Hz |
| AC Line Voltage | User selectable: 120V/240V (-15%,+10%) |
| AC Input Connecotr | PowerCon (NAC 3MPA) |
| AC Loop Through Connector | PowerCon (NAC 3MPB) |
| AC Current Requirements | 5A |
| Enclosure | 25/18mm birch plywood |
| Finish | Polyurea Finish |
| Grille | Powder coated, black, 16-gauge perforated steel with acoustically transparent foam |
| Dimensions Net | 349mm*597mm*444mm |
| Net Weight | 32KG |
Product description
The supplier lists this product as Active. Its stated application is Commercial. The listed model is VRX932. The specifications below reflect the information publicly displayed on the listing. Model NO.: VRX932. Speaker Material: Plywood. Model: Vrx932lap. Noise: <95dB.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Vrx932lap Powered Line Array Audio Speaker System?
The listed minimum order quantity is 20 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Vrx932lap Powered Line Array Audio Speaker System cost?
The published price is US$539.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
