W8lm Dual 8 Inch Three Way Touring Line Array Speaker, Mini Professional Audio System, Passive or Bi-AMP Operation, Neodymium Driver
- Application
- Commercial, Home
- Noise
- <95dB
- Hi-Fi
- Hi-Fi
- Activity
- Passive
- Operation Mode
- Wire / Remote Control
- Speaker System
- Optional Combination
Specifications
| Product name | W8lm Dual 8 Inch Three Way Touring Line Array Speaker, Mini Professional Audio System, Passive or Bi-AMP Operation, Neodymium Driver |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Noise | <95dB |
| Hi-Fi | Hi-Fi |
| Model NO. | W8LM |
| Activity | Passive |
| Operation Mode | Wire / Remote Control |
| Speaker System | Optional Combination |
| Speaker Material | Wood |
| Application | Commercial, Home |
| Certification | CE, RoHS, FCC |
| Monitor | LCD Screen |
| THD | <0.005% |
| Transport Package | Durable Cartons or Flight Case |
| Specification | 3 way line array |
| Origin | Made in China |
| HS Code | 8518220000 |
| Production Capacity | 500PCS/Month |
| Key Features | 1). Mini three-way line array element |
| Drivers | LF+MF section |
| LF + MF | 400W AES, 1600W peak ; HF: 75W AES, 300W peak |
| LF+MF | 100dB, HF:106dB |
| HF | 125dB continuous, 131dB peak |
| Dimensions | (W) 620mm * (H) 243 mm * (D) 400mm |
| Net Weight | 29kg |
| Company Home Page | https://cnsanway.en.made-in-china.com/ |
| Facebook Home Page | https://cnsanway.en.made-in-china.com/ |
| Price | US$200.00-500.00 1 Piece(MOQ) |
| Supplier | Sanway Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|
Additional data
| Model | W8LM |
|---|---|
| Drivers: LF+MF section | 8" (200mm)/2" (50mm) voice coil, reflex-loaded direct radiator 8" (200mm)/2" (50mm) voice coil, front horn loaded, rear reflex loaded |
| Drivers: HF section | 2 x 1" (25mm) exit HF compression drivers, horn loaded |
| Rated Power: | LF + MF: 400W AES, 1600W peak ; HF: 75W AES, 300W peak |
| Sensitivity: | LF+MF:100dB, HF:106dB |
| Maximum SPL | LF + MF: 125dB continuous, 131dB peak HF: 125dB continuous, 131dB peak |
| Nominal Impedance | LF + MF: 12 ohms HF: 12 ohms |
| Enclosure | Vertical , trapezoid with 3.75º wall angle, multi-laminate ply-wood construction |
| Finish | Textured paint |
| Protective Grille | Perforated steel |
| Connectors | 2xNeutrik NL4 |
| Dimensions: | (W) 620mm * (H) 243 mm * (D) 400mm |
| Net Weight: | 29kg |
Product description
The supplier lists this product. Its stated application is Commercial, Home. The listed model is W8LM. The specifications below reflect the information publicly displayed on the listing. Noise: <95dB. Model NO.: W8LM. Speaker Material: Wood. Drivers: LF+MF section.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for W8lm Dual 8 Inch Three Way Touring Line Array Speaker, Mini?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does W8lm Dual 8 Inch Three Way Touring Line Array Speaker, Mini cost?
The published price is US$200.00 – 500.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
W8LM · US$200.00 – 500.00 · MOQ 1 Piece
