Wholesale 100V White ABS Rimless Wall Mount Coaxial Ceiling Speaker with Protective Grill Covers for Indoor Ceiling
- Amplification Type
- Passive
- Speaker Material
- Plastic
- Power at 100V
- 7.5/15/30W; 60W at 8ohm
- Power at 70V
- 3.8/7.5/15W;60W at 8ohm
- Spl( 1W/1m)
- 90dB
- Max Spl@ 1m
- 103dB
Specifications
| Product name | Wholesale 100V White ABS Rimless Wall Mount Coaxial Ceiling Speaker with Protective Grill Covers for Indoor Ceiling |
|---|---|
| Category | Grilles, Cabinets & Enclosures |
| Customization | Available |
| Amplification Type | Passive |
| Speaker Material | Plastic |
| Model NO. | 210143 |
| Power at 100V | 7.5/15/30W; 60W at 8ohm |
| Power at 70V | 3.8/7.5/15W;60W at 8ohm |
| Spl( 1W/1m) | 90dB |
| Max Spl@ 1m | 103dB |
| Freq. Response | 50Hz-20kHz |
| Cutout Size | Dia 205mm |
| Installation | in Ceiling Mounted |
| Enclosure Material | ABS |
| Weight | 1.8kg |
| Speakers | 6" Coaxial |
| Transport Package | Gift Box/ Export Carton/ Pallet |
| Specification | Dia 235x160mm(H) |
| Origin | China |
| HS Code | 8518290000 |
| Production Capacity | 50000PCS Per Month |
| Price | US$22.00 50-99 Pieces US$20.00 100-299 Pieces US$16.90 300-499 Pieces US$16.00 500+ Pieces |
| Supplier | Guangzhou Temeisheng Audio Technic Co Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Plastic |
|---|---|
| Power at 100V | |
| Power at 70V | |
| Cutout Size | Dia 205mm |
| Enclosure Material | ABS |
Additional data
| Model | 210142/210223 | 210143/210224 | 210144/210206 |
|---|---|---|---|
| Power at 100V | 5/10/20W; 40W at 8ohm | 7.5/15/30W; 60W at 8ohm | 10/20/40W; 80W at 8ohm |
| Power at 70V | 2.5/5/10W;40W at 8ohm | 3.8/7.5/15W;60W at 8ohm | 5/10/20W;80W at 8ohm |
| SPL( 1W/1M) | 89dB | 90dB | 90dB |
| Max SPL@ 1M | 100dB | 103dB | 105dB |
| Freq. Response | 80Hz-20KHz | 50Hz-20KHz | 50Hz-20KHz |
| Product Size | Dia 205x146mm(H) | Dia 235x160mm(H) | Dia 281x180mm(H) |
| Cutout Size | Dia 180mm | Dia 205mm | Dia 255mm |
| Installation | In ceiling mounted | In ceiling mounted | In ceiling mounted |
| Enclosure Material | ABS | ABS | ABS |
| Weight | 1.3Kg | 1.8Kg | 2.6Kg |
| Finish | White | White | White |
| Speakers | 5" coaxial | 6" coaxia | 8" coaxial |
| 210142 | High performance rimless ceiling speaker 5 inch coaxial, 20W, 100V |
|---|---|
| 210223 | High performance rimless 5 inch, 5/10/20W 100V line; 40W 8 ohms coaxial ceiling speaker with fire dome |
| 210143 | High performance rimless ceiling speaker 6 inch coaxial, 30W, 100V |
| 210224 | High performance rimless 6 inch, 7.5/15/30W 100V line; 60W 8 ohms coaxial ceiling speaker with fire dome |
| 210144 | High performance rimless ceiling speaker 8 inch coaxial, 40W,100V |
| 210206 | High performance rimless 8 inch, 10/20/40W 100V line; 80W 8 ohms coaxial ceiling speaker with fire dome |
Product description
The supplier lists this product. The listed model is 210143. The specifications below reflect the information publicly displayed on the listing. Speaker Material: Plastic. Model NO.: 210143. Power at 100V: 7.5/15/30W; 60W at 8ohm. Power at 70V: 3.8/7.5/15W;60W at 8ohm. Enclosure Material: ABS.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Wholesale 100V White ABS Rimless Wall Mount Coaxial Ceiling Speaker?
The listed minimum order quantity is 50 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Wholesale 100V White ABS Rimless Wall Mount Coaxial Ceiling Speaker cost?
The published price is US$16.00 – 22.00 per piece, with lower tier prices for larger quantities. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
210143 · US$16.00 – 22.00 · MOQ 50 Pieces
