Yx16X800 97.5db 8 Ohm Large Magnet PA Loudspeaker Woofer
- Application
- Commercial, Home
- Certification
- CE, RoHS, FCC
- Speaker Material
- Metal
- Our letters patent
- Our cutting-edge technology and state-of-the-art facilities.
Specifications
| Product name | Yx16X800 97.5db 8 Ohm Large Magnet PA Loudspeaker Woofer |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Model NO. | YX16X800 |
| Certification | CE, RoHS, FCC |
| Transport Package | Carton |
| Specification | Sensitivity: 97.5db |
| Origin | Shengzhou |
| Package Size | 48.00cm * 48.00cm * 23.00cm |
| Package Gross Weight | 12.700kg |
| Customization | Available |
| Speaker Material | Metal |
| Application | Commercial, Home |
| Our letters patent | Our cutting-edge technology and state-of-the-art facilities. |
| We offer a variety of delivery options | DDP, FOB, CIF, CFR, EXW, and will select the most suitable method tailored to your needs. |
| Price | US$49.20-60.20 100 Pieces (MOQ) |
| Supplier | Kangzheng Acoustics (Zhejiang) Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Metal |
|---|
Additional data
| YX16X800 | ||
|---|---|---|
| Nominal Diameter | 416/16 | mm/inch |
| Nominal Impedance | 8 | Ohm |
| Power Rating | 800+80 | Watts |
| Power MAX | 1600+160 | Watts |
| Sensitivity | 97.5 | dB |
| Frequency Range | 40-2500 | Hz |
| Magnet Diameter | 220x110x25/125 | mm/OZ |
| Voice Coil Diameter | 99.2/4 | mm/inch |
| Minimum Impedance | 5.3 | Ohm |
| Voice Coil Material | Copper | |
| Former Material | Glass Fiber | |
| Voice Coil Winding Height | 23/0.9 | mm/inch |
| Number of layers | inside/outside |
Product description
The supplier lists this product. Its stated application is Commercial, Home. The listed model is YX16X800. The specifications below reflect the information publicly displayed on the listing. Model NO.: YX16X800. Speaker Material: Metal.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for Yx16X800 97.5db 8 Ohm Large Magnet PA Loudspeaker Woofer?
The listed minimum order quantity is 100 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does Yx16X800 97.5db 8 Ohm Large Magnet PA Loudspeaker Woofer cost?
The published price is US$49.20 – 60.20 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
YX16X800 · US$49.20 – 60.20 · MOQ 100 Pieces
