1.7inch 250-8 Ferrite Ccar Tweeter Sound PRO Compression Driver Speaker
- Power
- 50W
- Type
- Compression Driver
- Phase Plug
- CNC Plastic
- Diaphragm
- Pen
- Magnet
- Y35A Ferrite
- Back Cover
- Alu
Specifications
| Product name | 1.7inch 250-8 Ferrite Ccar Tweeter Sound PRO Compression Driver Speaker |
|---|---|
| Category | Speaker Drivers, Woofers & Tweeters |
| Customization | Available |
| Phase Plug | CNC Plastic |
| Diaphragm | Pen |
| Model NO. | H25-44 |
| Power | 50W |
| Magnet | Y35A Ferrite |
| Type | Compression Driver |
| Back Cover | Alu |
| Transport Package | Strong Carton |
| Specification | Shipping Weight (10unit) 24.6 kg |
| Origin | Guangzhou, China |
| HS Code | 8518290000 |
| Production Capacity | 3000/Month |
| https | //ruizhengsound.en.made-in-china.com/product/qXkQFRaECOpK/China-3inch-High-Precise-Y35A-Ferrite-1-4-quot-Throat-Compression-Driver-Speaker.html |
| Price | US$22.00-30.00 2 Pieces(MOQ) |
| Supplier | Foshan Ruizheng Audio Co.,Ltd |
| Data retrieved | 2026-10-23 |
Available options
| Power | 50W |
|---|
Additional data
| MODEL H25-44 | ||||
|---|---|---|---|---|
| Specifications | Thiele Small Parameters | |||
| TYPE | Compression driver | Fs | 1000 Hz | |
| Exit Throat Diameter | 25.4 mm/1 in | Re | 5.8 ohm | |
| Rated impedance | 8 ohm | Diaphragm Material | PEN | |
| Nominal (AES) | 50 W | Suspension Material | PEN | |
| Continuous Program | 100 W | Magnet | Ferrite | |
| Sensitivity(1w/1m) | 107 dB | Phase plug | Plastic | |
| Frequency Range | 1000Hz-18000Hz | |||
| Voice Coil Diameter | 44.4 mm/1.7 in | |||
| Voice Coil Material | ALR outside | |||
| Mounting lnformation | Shipping lnformation | |||
| Overall Diameter | φ120 mm/φ4.7 in | Net Weight (1unit) | 2.3 kg | |
| Bolt Circle Diameter | φ76 mm/φ3.0 in | Shipping Weight (10unit) | 24.6 kg | |
| Bolt Hole Diameter | 2-M6mm/2-M0.24 in | Package Size (10unit) | 34x27x18 cm | |
| Depth | 63 mm/2.5 in |
Product description
The supplier lists this product as Compression Driver. The listed model is H25-44. The specifications below reflect the information publicly displayed on the listing. Model NO.: H25-44. Power: 50W.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 1.7inch 250-8 Ferrite Ccar Tweeter Sound PRO Compression Driver?
The listed minimum order quantity is 2 pieces. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 1.7inch 250-8 Ferrite Ccar Tweeter Sound PRO Compression Driver cost?
The published price is US$22.00 – 30.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
