12” Line Array Speaker System, 800W Power Professional Woofer /Midbass Loudspeaker
PA, Stage & Line-Array Speakers

12” Line Array Speaker System, 800W Power Professional Woofer /Midbass Loudspeaker

Model: 12FW75V1 Customization available Speakers & Audio Systems
US$12.00 – 38.00
MOQ 1 Piece
Impedance
8 Ohm
Sensitivity
97 dB
Application
Stage
Activity
Passive
Operation Mode
No
Speaker Material
Plastic
Send Inquiry Full specifications

Specifications

Product name12” Line Array Speaker System, 800W Power Professional Woofer /Midbass Loudspeaker
CategoryPA, Stage & Line-Array Speakers
CustomizationAvailable
ActivityPassive
Model NO.12FW75V1
Operation ModeNo
Speaker MaterialPlastic
ApplicationStage
CertificationCE, RoHS, FCC
AES Power Rating400 W
Program Power800 W
Frequency Range58-3500Hz
Voice Coil3''vc Ccaw in/out
Sensitivity97 dB
Impedance8 Ohm
MagnetFerrite
ChassiaAluminum
Transport PackageCarton
Specification325 x 325 x 175 mm
OriginChina
HS Code8518290000
Production Capacity50000
PriceUS$12.00-38.00 1 Piece(MOQ)
SupplierGUANGDONG HIWELL AUDIO CO., LTD
Data retrieved2026-10-23

Available options

Speaker MaterialPlastic
AES Power Rating400 W
Program Power800 W
Impedance8 Ohm

Additional data

Nominal diametermm (in.)311(12)
Nominal impedanceΩ8
Minimum impedanceΩ6.6
Program power (1)W800
AES Power rating(2)W400
Sensitivity (3)dB97
Frequency rangeHz58 ~ 3500
Voice coil diametermm (in.)75(3)
Chassis materialAluminum
Magnet materialFerrite
Magnet dimensions (ODxIDxh)mm170 x 85 x 20
Coil materialCCAW
Former materialGlass Fiber
Xmax(4)mm6
Xmech(5)mm11.5
Gap heightmm9
Voice coil Wingding heightmm18
DC resistanceReOhm5.3
Resonance frequencyFsHz58
Moving massMmsg65
ComplianceCmsmm/N0.15
Force factorBLN/A17.5
Mechanical Q-factorQms4.3
Electrical Q-factorQes0.36
Total Q-factorQts0.33
Equivalent air volumeVasI60
Voice coil InductanceLemH0.75
Diaphragm areaSdcm²542
Reference efficiencyEta 0%2.6
Net weightKg5.4
Multipack size (1) (W x D x H)mm325 x 325 x 175
Multipack weightKg6

Product description

The supplier lists this product. Its stated application is Stage. The listed model is 12FW75V1. The specifications below reflect the information publicly displayed on the listing. Noise: 0. Model NO.: 12FW75V1. Speaker Material: Plastic. AES Power Rating: 400 W. Program Power: 800 W. Frequency Range: 58-3500Hz. Sensitivity: 97 dB. Impedance: 8 Ohm.

Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.

FAQ

What is the minimum order quantity for 12” Line Array Speaker System, 800W Power Professional Woofer?

The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.

How much does 12” Line Array Speaker System, 800W Power Professional Woofer cost?

The published price is US$12.00 – 38.00 per piece. Final pricing depends on quantity, options and destination.

Can it be customized with my logo, color or packaging?

Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.

Where do these specifications come from?

Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
