15 Inch Passive Subwoofer and 12 Inch Point-Source Loudspeaker Sound Equipment Professional Stage Speakers
- Type
- Passive Speaker
- Application
- Commercial, Home
- Operation Mode
- Wire / Remote Control
- Speaker System
- Optional Combination
- Speaker Material
- Wood
- Certification
- CE, RoHS
Specifications
| Product name | 15 Inch Passive Subwoofer and 12 Inch Point-Source Loudspeaker Sound Equipment Professional Stage Speakers |
|---|---|
| Category | PA, Stage & Line-Array Speakers |
| Customization | Available |
| Operation Mode | Wire / Remote Control |
| Speaker System | Optional Combination |
| Model NO. | TN-24 and BN-30 |
| Speaker Material | Wood |
| Application | Commercial, Home |
| Certification | CE, RoHS |
| Monitor | No |
| Type | Passive Speaker |
| Cabinet | First Grade Russian Birch Plywood |
| Speaker Driver | Neodymium Magnet |
| Splmax | 143 Db |
| Frequency Range | 65-18kHz |
| Transport Package | Strong Wooden Frame and Carton |
| Specification | 70&45&45cm |
| Origin | Guangdong Province, China |
| HS Code | 85182200 |
| Package Size | 90.00cm * 60.00cm * 60.00cm |
| Package Gross Weight | 33.000kg |
| LF | 2 × 12" |
| HF | 1 × 1.4" exit with 3" diaphragm |
| T-24N Feature | 1. Coming with 2x12" High efficiency Neodymium Drivers |
| BT-30 Features | 1. Horn-loaded bass reflex hybrid design |
| Price | US$1,200.00-1,500.00 1 Piece(MOQ) |
| Supplier | Guangzhou Xinbaosheng Audio Equipment Co., Ltd. |
| Data retrieved | 2026-10-23 |
Available options
| Speaker Material | Wood |
|---|
Additional data
| T-24N Product Parameters | |
|---|---|
| Drivers | LF: 2 × 12" |
| HF: 1 × 1.4" exit with 3" diaphragm | |
| Frequency range | 65 - 18kHz |
| Power capacity program / peak | 1400 / 2400 W (bi-amp LF), 220 / 400 W (bi-amp HF) 1400 / 2400 W (passive) |
| Impedance | 4 Ω (bi-amp LF), 8 Ω (bi-amp HF) 4 Ω (passive) |
| Coverage (h × v) | 60° × 40° or 90° × 50° HF-horn, exchangeable, rotatable |
| Sensitivity 1 W / 1 m | 107 dB (bi-amp LF), 112 dB (bi-amp HF) 110 dB (passive) |
| SPLmax / 1 m | 143 dB |
| Dimensions (H × W × D) | 706 × 440 × 440 mm |
| Weight | 33 kg |
| Finish | Warnex texture paint |
| BT-30 subwoofer speaker | |
|---|---|
| Driver | 2 × 15" |
| Frequency range | 35-200 Hz |
| Power capacity program /peak | 2000 / 4000 w |
| lmpedance | 8 Ω |
| Coverage | omni |
| Sensitivity 1w / 1 m | 97 dB |
| SPLmax / 1 m | 133 dB |
| Dimensions (Hx W× D) | 706 x 446 x 8o0 mm [27.8×17.56 × 31.5 in] |
| Weight | 38,7 kg [85 lbs] |
| Finish | Polyurea coating, black |
| Enclosure cabinet | First grade birch plywood |
| Front | Perforated, powder-coated steel Flame retardant, hydrophobic and acoustically transparent 3D mesh fabric |
Product description
The supplier lists this product as Passive Speaker. Its stated application is Commercial, Home. The listed model is TN-24 and BN-30. The specifications below reflect the information publicly displayed on the listing. Model NO.: TN-24 and BN-30. Speaker Material: Wood. Speaker Driver: Neodymium Magnet. Frequency Range: 65-18kHz.
Specifications, options and prices reproduce the supplier's published listing. Please confirm critical parameters with us before ordering.
FAQ
What is the minimum order quantity for 15 Inch Passive Subwoofer and 12 Inch Point-Source Loudspeaker Sound?
The listed minimum order quantity is 1 piece. Tell us your quantity in the inquiry form and we will confirm it with the manufacturer.
How much does 15 Inch Passive Subwoofer and 12 Inch Point-Source Loudspeaker Sound cost?
The published price is US$1,200.00 – 1,500.00 per piece. Final pricing depends on quantity, options and destination.
Can it be customized with my logo, color or packaging?
Yes — the listing states that customization is available (Available). Describe your requirements in the inquiry.
Where do these specifications come from?
Specifications, options and prices reproduce the manufacturer's published listing on the date shown in the specification table. Please confirm critical parameters before ordering.
Send an inquiry
TN-24 and BN-30 · US$1,200.00 – 1,500.00 · MOQ 1 Piece
